IntesisBox ASCII Server - KNX
8. EIS. KNX data type (Data point) to encode the signal's value. Possible values are:
switching (1 bit), dimming (4 bit), float (16 bit), scaling (8 bit), drive control (1 bit),
priority (2 bit), float IEEE (32 bit), counter (8 bit), counter (16 bit), counter (32 bit),
ASCII char (8 bit). Edit using the mouse right-button-click menu available on the
column.
9. Group. Main EIB group address for the signal. Format: P/I/S or P/S. Flags R,W,T,U
explained below will only apply for this main EIB group address, not for listening
addresses (if defined). It is the sending group address.
10. Listening addresses. EIB group addresses that will be listen by IntesisBox for this signal,
that is to say, if IntesisBox receives an EIB telegram with destination one of these
listening addresses, then the telegram will be taken into account and the corresponding
action will be performed on this signal. Format: P/I/S or P/S, if more than one is entered
then they must be separated by comma.
11. R. Indicates if this signal is allowed to be read from KNX system. Possible values: "R" or
blank. "R" means flag activated.
12. W. Indicates if this signal is allowed to be written from KNX system. Possible values:
"W" or blank. "W" means flag activated.
13. T. Indicates if this signal will generate a telegram sending to the KNX system following a
change of the signal's value, that is to say, any change of value of this signal in ASCII
side will be transmitted to the KNX system if this flag is activated. Possible values: "T" or
blank. "T" means flag activated.
14. U. Indicates if this signal will be updated whenever IntesisBox starts up or after an EIB
bus reset. "U" means flag activated for the main EIB group address (a read of the main
EIB group address will be performed in the KNX system for the update). "U2" means flag
activated for the first listening address defined (a read of the first listening address
defined for the point will be performed in the KNX system for the update). Blank means
flag not activated. Edit using the mouse right-button-click pop-up menu available on the
column.
15. Active. Indicates if the signal is active or not for the integration. Possible values: 0-No,
1-Yes. Edit using the mouse right-button-click menu available on the column.
16. Buttons to move the selected row (or rows) up or down inside the grid. To move up or
down inside the grid a single row or a group of consecutive rows, just select the row or
rows using the left button of the mouse and push the desired up or down button. (This
can be done also using the key combinations ALT+arrow up or ALT+arrow down instead
of up or down buttons).
