Application information
208
720p 50: available for format HD 720 only
720p 59.94: available for format HD 720 only
720p 60: available for format HD 720 only
1080i 50: available for format HD 1080
1080p 50: available for format 3G LevelA
1080i 59.94: available for format HD 1080
1080p 59.94: available for format 3G LevelA
1080i 60: available for format HD 1080
1080p 60: available for format 3G LevelA
Pattern: Use this drop down list to select from the following patterns: Black
or 100% Color Bars.
Motion: Use this button to enable or disable horizontal motion of the color
bars.
NOTE.
The Motion option is unavailable when Pattern is set to Black.
Video Transport. The following options are available under the Video Transport
settings.
Packing Mode: Use this option to select one of the following packing modes:
Block: Block Packing Mode is based on 180 byte blocks and supports
many formats.
General: General Packing Mode follows the open packing standards of
RFC 4175.
RTP Payload Type: Use this setting to give the generated IP stream a RTP
Payload Type number between 96 to 127.
NOTE. Each generated IP stream must have a unique RTP Payload Type number.
Packet Read Schedule (PRS): Use this option to select one of the following
read schedules:
Gapped: Gapped PRS reads packets at an equally spaced sequence
throughout the active field or frame interval and accounts for vertical
blanking (gaps).
Narrow (Linear): Narrow (linear) PRS reads the packets at an equally
spaced sequence throughout a video frame.
