Application information

Diamond display application

Figure 102: Diamond display application
Diamond application
banner
126
The Diamond application provides a tool for white and black balancing at camera
setup and for color gamut adjustment at color editing and QC. For additional
information on how to use the Diamond display application refer to the Checking
gamut section. (See page 128.)
The following figure shows the available options after pressing and holding
anywhere on the Diamond application tile.
Figure 103: Diamond application banner
The following options adjust how the Diamond application is displayed:
The maximize icon ( ) expands the Diamond application tile to the full
screen. The minimize icon ( ) collapse the tile back to its original size.
