Figure 99: Vector on-screen tools – horizontal position
PRISM MPI and MPX Media Analysis Platform User Manual
Horizontal and vertical position. Adjust the position of the trace display.
1. Touch the H Pos button to allow adjustment of the horizontal trace.
Touch and drag to move the trace on the touch screen. This method can be
performed without using the button.
Use a mouse scroll wheel to move the trace.
For incremental adjustments, use the plus or minus button to adjust the
horizontal position.
Use the
icon to reset the horizontal position adjustment to default.
Application information
123
