How to recall the Factory
preset
PRISM MPI and MPX Media Analysis Platform User Manual
Perform the following steps to recall the Factory preset:
1. Touch the Settings icon (
2. Select Presets to open the Presets submenu.
3. Select Recall Factory Preset. A confirmation box opens as shown below.
Figure 58: Presets Rename submenu
4. Select OK to confirm the selection and to reset the instrument settings to
the factory defaults.
The following table lists the instrument settings that are reset by recalling the
Factory preset.
NOTE.
Custom presets will still be available after recalling the Factory preset.

Table 6: Instrument settings that are reset by recalling the Factory preset

Item
Tile 1 application
Tile 2 application
Tile 3 application
Tile 4 application
SDI-In 1 input configuration
Input name
Input type
Input connector
SDI-In 2 input configuration
Input name
Input type
Input connector
How to configure the instrument
) to open the Settings menu.
Setting
Waveform
Video Session
Audio
SDI-In 1
SDI
SDI 1
SDI-In 2
SDI
SDI 2
