Application information
Eye Display application
settings menu
144
The following options adjusts the Eye Display application:
The maximize icon ( ) expands the Eye Display application tile to the full
screen. The minimize icon ( ) collapse the tile back to its original size.
NOTE.
The display readouts will only display when the tile is expanded to full
screen.
The expand icon ( ) expands or collapses the tile vertically. If the tile
expands it will cover the tile above or below, depending on whether you are
expanding the top or bottom quarter tile. Use the collapse icon ( ) to bring
the tile back to its original size.
The gear icon ( ) opens the Eye Display application settings menu to adjust
the tile settings.
NOTE. After the Eye Display application settings menu is opened, a move icon
( ) is displayed. Press this icon to move the settings menu horizontally.
The following figure shows the different choices in the Eye Display application
settings menu.
Figure 123: Eye Display application settings menu
