0226267en
003
12.2010
Vibratory plate
DPU 5545He
Operator´s Manual

Advertisement

Table of Contents
loading

Related Manuals for Wacker Neuson DPU 5545He

Summary of Contents for Wacker Neuson DPU 5545He

  • Page 1 0226267en 12.2010 Vibratory plate DPU 5545He Operator´s Manual...
  • Page 2 Manufacturer Wacker Neuson SE Preußenstraße 41 80809 München www.wackerneuson.com Tel.: +49-(0)89-354 02-0 Fax: +49-(0)89-354 02-390 Translation of the original operator's manual in German...
  • Page 3 Foreword This operator's manual contains information and procedures for the safe opera- tion and maintenance of your Wacker Neuson machine. In the interest of your own safety and to prevent accidents, you should carefully read through the safety information, familiarize yourself with it and observe it at all times.

  • Page 4: Table Of Contents

    Table Of Contents Technical Data Description Dimensions ..................23 Max. admissible inclination ..............23 Description of function .................24 Transport to work site /Recommendations on compaction Transport to work site ................26 Recommendations on compaction ............27 Operation Starting ....................28 Forward and reverse motion ...............29 Switching off ..................30 Compaction without extension plates ..........30 Emergency start by hand ..............30...
  • Page 5 Table Of Contents Forward speed too low ................41 Reverse speed too low ................41 No reverse motion ................41 Loss of hydraulic oil ................41 The charge control lamp will not extinguish ........42 Engine does not start ................42...
  • Page 6 Installation of accessories which are not from Wacker Neuson. It is no problem to install spare parts from Wacker Neuson. It is no problem to install accessories that are available in the Wacker Neuson product range of your machine. Please refer to the installation regulations in this operator's manual.
  • Page 7 Have damaged or defective components replaced immediately! For further information, refer to chapter Troubleshooting. Spare parts, accessories Use only spare parts from Wacker Neuson or such that are equivalent to the orig- inal parts in design and quality. Only use accessories from Wacker Neuson.
  • Page 8 2 Safety Exclusion of liability Wacker Neuson will refuse to accept liability for injuries to persons or for damage to materials in the following cases: Structural modifications. Improper use. Failure to comply with this operator's manual. Improper handling. Using of spare parts which are not from Wacker Neuson and not equivalent to the original parts in design and quality.

  • Page 9: Qualification Of The Operating Personnel

    2 Safety Checking for signs of damage Inspect the machine when it is switched off for any signs of damage at least once per work shift. Do not operate the machine if there is visible damage or defects. Have any damage or defects eliminated immediately. Qualification of the operating personnel Operator qualifications Only trained personnel are permitted to start and operate the machine.
  • Page 10 When wearing ear protection while working, you must pay attention and exercise caution because your hearing is limited, e.g. in case someone screams or a sig- nal tone sounds. Wacker Neuson recommends that you always wear ear protection. Transport Switching off the machine Before you transport the machine, it must be switched off, and the engine must be given sufficient time to cool down.
  • Page 11 2 Safety Lifting When lifting the machine, observe the following instructions: Designate a skilled person to guide you for the lifting procedure. You must be able to see or hear this person. Use only suitable and certified hoisting gear, lifting tackle and load-bearing equipment with sufficient lifting capacities.
  • Page 12 2 Safety Work environment Familiarize yourself with your work environment before you start work. This in- cludes e.g. the following items: Obstacles in the work and traffic area. Load-bearing capacity of the ground. The measures needed to cordon off the construction site from public traffic in particular.
  • Page 13 2 Safety Switching off the machine Switch off the engine in the following situations: Before breaks. If you are not using the machine. Store the machine in such a way that it cannot tilt, fall or slip. Storage location After operation, allow the machine to cool and then store it in a sealed-off, clean and dry location protected against frost and inaccessible to children.
  • Page 14 You must also comply with the relevant guidelines and regulations, particularly DIN 4150-3. The foundation must also have sufficient load-bearing capacity to withstand the compaction energy. In case of doubt involve a soil mechanics specialist in the evaluation. Wacker Neuson is not liable for any structural damage. Operator's manual...
  • Page 15 2 Safety Safety during the operation of combustion engines Checking for signs of damage Check the engine while switched off for leaks and cracks in the fuel line, tank and fuel cap at least once per work shift. Do not operate the machine if there is visible damage or defects. Have any damage or defects eliminated immediately.
  • Page 16 This machine is equipped with an EPA-certified engine. Modifying the motor speed influences the EPA certification and emission. The motor may only be set by a skilled technician. For more detailed information, contact your nearest motor or Wacker Neuson representative. Operator's manual...
  • Page 17 Using only a Wacker Neuson battery Use only Wacker Neuson batteries to replace defective batteries, see chapter Technical Data. Only the Wacker Neuson battery is vibration resistant and thus suitable for the high vibratory stresses. Operator's manual...
  • Page 18 Dispose of replaced or spilled operating fluids according to the applicable regulations for environmental protection. If operating fluids escape from the machine, cease operation of the machine and have it repaired immediately by your Wacker Neuson representative. Operator's manual...

  • Page 19: Safety And Information Labels

    2 Safety 2.10 Safety and information labels Your machine has adhesive labels containing the most important instructions and safety information. Make sure that all the labels are kept legible. Replace any missing or illegible labels. The item numbers for the labels are in the parts book. Pos.
  • Page 20 2 Safety Pos. Label Description If the machine falls, it can cause severe crushing injuries. Do not lift the machine by the guide handle or the center pole. DPU 45.., DPU 55.. Warning Parts of the body could be crushed or se- vered by rotating engine parts.

  • Page 21: Technical Data

    Technical Data Technical Data DPU 5545Heap DPU 5545He Item no. 0610353 0610351, 0610402 Operating weight Forward/reverse speed m/min: Surface compaction performance 1109 Power transmission From drive engine directly to exciter unit via automatic centrifugal and V-belts Exciter Vibrations Centrifugal force...
  • Page 22 Technical Data DPU 5545Heap DPU 5545He Battery Special Wacker Neuson-battery for vibro plates - 12 V - 55 Ah Alternator Rotary current generator with electronic regulator and rectifier Charging rate max. Charging voltage Starter Starter motor D.C. Hydraulic control Hydraulic oil...

  • Page 23: Description

    Description Description Dimensions Max. admissible inclination T00994GB.fm...

  • Page 24: Description Of Function

    Description Description of function 2.3.1 The vibration required for compaction is produced by the exciter (13) which is firmly joined to the lower mass (5). This exciter (13) is designed as a central vibrator with aligned vibrations. Such a principle permits the direction of vibration to be changed by turning the eccentric weights (15).
  • Page 25 Description 2.3.3 The centrifugal clutch (11) interrupts flow of power to the exciter (13) at low engine speed and thus permits perfect idling of the drive engine (1). 2.3.4 The automatic V-belt pulley (10) combined with the centrifugal clutch (11) ensures optimum tension of the exciter V-belt (12) during operation and relief of the tension of the exciter V-belt (12) when the machine is being relocated or transported.

  • Page 26: Transport To Work Site /Recommendations On Compaction

    Transport to work site /Recommendations on compaction Transport to work site /Recommendations on compaction Transport to work site Conditions: ∗ To transport the vibration plate, only use suitable lifting equipment with a minimum load-bearing capacity of 500 kg. ∗ Always switch off engine before transporting the machine! ∗...

  • Page 27: Recommendations On Compaction

    Transport to work site /Recommendations on compaction Recommendations on compaction 3.2.1 Ground conditions The max. compaction depth depends on several factors relating to the ground condition, such as moisture, grain distribution etc, it is therefore not possible to specify exact values. Recommendation: In each case determine the max.

  • Page 28: Operation

    Operation Operation Starting 4.1.1 Conditions: Oil: Check oil level with oil dipstick (21), if necessary top up with Fuchs Titan Unic 10W40 MC through oil filler neck (19). Fuel: When pouring diesel fuel into the filler neck (20), maintain absolute cleanliness.

  • Page 29: Forward And Reverse Motion

    Operation 3. Turn ignition switch key (22) to operating position; then push in starter button and hold until engine is running. Wait until the engine stops before repeating the starting procedure. 4. Turn throttle control lever (8) into idling position, allow engine to warm up for 7 minutes at idling speed.

  • Page 30: Switching Off

    Operation Switching off Never switch off the engine with the automatic decompression (2) as this inevitably results in damage to the valve drive and decompression mechanism. 1. Move the throttle control lever (8) to the stop. 2. When the engine is at a standstill, turn the ignition key (22) to the Stop position and pull out, control lamp goes off.
  • Page 31 Operation 1. Turn the throttle control lever (8) to the full load position. 2. Following the direction of long arrow, turn the decompression lever until the stop position. At this point automatic decompression lever engages with an audible click, and the engine is ready to start. 3.

  • Page 32: Mechanical Oil Pressure Control

    Operation Mechanical oil pressure control It is necessary to reactivate the mechanical oil pressure control in the following cases: ∗ after the initial filling - first filling - of the fuel tank or if the tank has run dry. ∗ in the case of an automatic engine stop due to an inefficient engine oil supply.

  • Page 33: Starting With External Battery Etc

    Operation Starting with external battery etc. 4.7.1 Essential requirements for battery jumper cable: ∗ Cable cross-section must be at least 16 mm . (2.5 sq. inches). ∗ Clamps must be completely insulated with plastic. Only connect 12 Volt batteries. The on-board battery will explode if connected to a 24 Volt truck battery! The use of starter sprays is absolutely forbidden! External (donor) battery...

  • Page 34: Additional Notes On Starting At Very Low Temperatures

    Operation Additional notes on starting at very low temperatures! Never use starting sprays or similar - they are forbidden because they are dangerous. Only use original Wacker crank. If cranking, is too slow, the engine can start running in the opposite direction of rotation.

  • Page 35: Maintenance

    Maintenance Maintenance Maintenance schedule Maintenance Component Maintenance work interval Drive engine First oil change and filter. approx. 8 hours Cold engine: Check valve clearance, and adjust if after initial start-up Valve clearance necessary. Inlet valve 0,1 mm - outlet valve 0,2 mm. Check dry type air filter - clean or replace filter Air filter cartridge if necessary (pay attention to the...

  • Page 36: Engine Oil

    Maintenance Engine oil 5.2.1 Check oil level: ∗ Check oil level with oil dipstick (21). ∗ .If the oil level is too low, top up with Fuchs Titan Unic 10W40 MC though the filler neck (19). 5.2.2 Changing the oil: 1.

  • Page 37: Batterry

    Maintenance Batterry 5.3.1 Check acid level: 1. Remove battery cover. 2. Check acid level, if necessary top up with distilled water. 3. Secure battery cover. Do not close venting opening! Note: Only replace defective batteries with original Wacker batteries. Standard batteries are not suitable for the high vibration loads. 4.

  • Page 38: Hydraulic Control

    Maintenance Hydraulic control 5.4.1 Check oil level: 1. Move centre pole into vertical position. 2. Open filler bore (26). 3. Oil level must be at mark, if necesary top up with hydraulic oil Fuchs Renolin MR 520. 4. Close filler bore (26). 5.4.2 Venting hydraulic control: 1.

  • Page 39: Exciter

    Maintenance Exciter 5.5.1 Check oil level: 1. Position vibration plate horizontally. 2. Open filler bore (30). 3. The oil level must reach the start of the thread of the filler bore. 4. If necessary, pour in Fuchs Titan Unic 10W40 MC through filler bore (use funnel 0,75 l).

  • Page 40: Exciter V-Belt

    Maintenance Exciter V-belt It is not necessary to retighten the V-belt owing to the use of the automatic centrifugal clutch. Should the V-belt width fall below 15,5 mm the V-belt must be replaced. 5.6.1 Changing the exciter V-belt: 1. Remove belt guard (31). 2.

  • Page 41: Faults

    Too much hydraulic oil in centre pole Correct oil level in accordance with head. mark. No reverse motion Cause Remedy Mechanical fault. Contact Wacker Neuson service dept. Loss of hydraulic oil Cause Remedy Leaks, hydraulic hose defective. Contact Wacker Neuson service dept. T00998GB.fm...

  • Page 42: The Charge Control Lamp Will Not Extinguish

    Faults The charge control lamp will not extinguish Cause Remedy Dynamo defective. Contact Wacker Neuson service dept. Replace control unit (on rear of the Control unit defective. dynamo). Engine does not start Cause Remedy Ignition lock defective. Starter defective. Change defective parts.
  • Page 43 3 Disposal Disposal Disposal of batteries For customers in EU countries This device contains one or more batteries or rechargeable batteries (hereafter referred to as "batteries"). This battery is subject to the European Directive 2006/66/EC on (waste) batteries, as well as the corresponding national legisla- tion.

  • Page 44: Emission Control Systems Information And Warranty

    4 Emission control systems information and warranty Emission control systems information and warranty The Emission Control Warranty and associated information is valid only for the U.S.A., its territories, and Canada. Emission control systems warranty statement See the engine owner’s manual for the applicable exhaust and evaporative emis- sion warranty statement.

  • Page 45: Ec Declaration Of Conformity

    EC Declaration of Conformity Manufacturer Wacker Neuson SE Preußenstraße 41, 80809 München Product Type DPU 5545 Product type Vibrating plate Item no. 0610351, 0610352, 0610353 Installed power output Measured sound pow- dB(A) 107 er level Guaranteed sound dB(A) 108 power level Conformity assessment procedure acc.
