- Page 1 0203032en 03.2007 Electric-breaker EH 27/115 Double insulated Operator´s Manual...
-
Page 3: Safety Instructions
Safety instructions Safety instructions WARNING! When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following. READ ALL THESE INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS PRODUCT AND SAVE THESE INSTRUCTIONS. SV00030GB.fm... -
Page 4: Table Of Contents
Table of contents Safety instructions Foreword Safety instructions General Instructions ................8 Operation ....................8 Safety checks ..................10 Maintenance ..................11 Transport .....................11 Maintenance checks ................11 Technical Data Description Field of application ................13 Functional description .................13 Transport to work site Operation Attaching the tool .................15 Connection ..................15 Notes on correct handling ..............16 Maintenance... - Page 5 Table of contents 12. Disposal 12.1 Environmentally friendly reuse ............23 EC - Conformity Certificate DIN EN ISO 9001 Certificate...
- Page 6 Table of contents...
-
Page 7: Foreword
Foreword Foreword For your own safety and protection from bodily injuries, carefully read, understand and follow the safety instructions in this manual. Please operate and maintain your Wacker machine in accordance with the instructions in this manual. Your Wacker machine will reward your attention by giving trouble-free operation and a high degree of availability. -
Page 8: Safety Instructions
Safety instructions Safety instructions for the use of drilling and breaking hammers with electric drive General Instructions 3.1.1 Drilling and breaking hammers may only be operated by persons who ∗ are at least 18 years of age, ∗ are physically and mentally fit for this job, ∗... - Page 9 Safety instructions 3.2.3 The operator has to switch off drilling and breaking hammers, to disconnect them from the electric mains and to store them in such a manner that they do not turn over be fore leaving the machines or going on breaks.
-
Page 10: Safety Checks
Safety instructions 3.2.13 Drilling and breaking hammers have to be disconnected from the electric mains before changing tools. 3.2.14 The tools always have to be in perfect conditions. 3.2.15 Do not operate this machine in areas where explosions may occur. 3.2.16 Do not misuse the electric cable to pull or lift up the unit or to pull the plug out of the socket. -
Page 11: Maintenance
Safety instructions Maintenance 3.4.1 Only use original spare parts. Modifications to this machine are subject to the express approval of the Wacker Company. All liabilities shall be refused in case of nonobservance. 3.4.2 Disconnect the drilling and breaking hammer from the electric mains before carrying out maintenance and repair jobs. -
Page 12: Technical Data
Technical Data Technical Data EH 27/115 Item no. 0008396 Length x width x height (without tool) 710 x 529 x 210 Operating weight (mass) without tool Voltage 110 - 127 1 Power input Current consumption Frequency 50 / 60 Percussion rate... -
Page 13: Description
Description Description Field of application For breaking concrete and asphalt as well as rubble-laden ground, for demolishing concrete, masonry and similar building materials (undisturbed and frozen ground) etc., for ripping up roads and concrete, asphalt, tar as well as wood-block and stone paving, for cutting off clay, loam, turf and salts, for breaking compacted or tamped ground, for ramming in posts and earth rods. -
Page 14: Transport To Work Site
Transport to work site Transport to work site Conditions: ∗ Only use appropriate lifting gear with a minimum load bearing capacity of 30 kg (66 pounds) for the transport of your Wacker machine. ∗ Always switch off engine during transport! ∗... -
Page 15: Operation
Operation Operation Attaching the tool 1. Swivel catch (9) on tool holder (11) outwards. 2. Clean shaft (10) and grease slightly. 3. Insert tool right in. 4. Press catch (9) on tool holder (11) right back. Only use sharp tools! Only use tools with perfect shaft (10) to avoid recoil! Connection Check before connecting:... -
Page 16: Notes On Correct Handling
Operation Notes on correct handling Place the electric breaker with tool on the material in question and switch on by pressing the switch lever. After a few seconds the electric breaker reaches its full percussion rate. Exploit the weitht of the electric breaker when working. Applying great force against the surface being worked does not improve the performance of the tool. -
Page 17: Maintenance
Maintenance Maintenance Maintenance schedule Maintenance Component Maintenance work interval Feed cable Check for perfect condition, change if defective. Protective hood Ventilations slits free of dirt, clean if necessary. daily Check the shaft and cutting edges and, if Tools necessary, sharpen, reforge or replace. Motor head Regrease via grease nipple (see technicla data) 20 hours... -
Page 18: Carbon Brushes
Maintenance Carbon brushes Check carbon brushes: 1. Replace carbon brushes (16) if the surface has been worn down unevenly. 2. Replace carbon brushes (16) if the are less than 12 mm long. If shut-down device has triggered replace carbon brushes (16). Lubrication of the motor and transmission The sealed motor armature bearing and the transmission mean that additional lubrication with in the maintenace interval of 300 hours is... -
Page 19: Lubrication Of The Tool Holder, Tolerances
Maintenance Lubrication of the tool holder, tolerances 8.5.1 Only insert tools (18) with a cleaned and slightly greased shaft (10) into the tool holder (11). 8.5.2 Check the tool holder often for signs of wear. A tool in new condition (18) may exhibit tolerance of no more than 10 mm at a distance of 400 mm from the insertion end’s (1) rest collar. -
Page 20: Electriwiring Diagram
Electriwiring diagram Electriwiring diagram Motor Cover with terminal board Switch Plug SK00681GB.fm... -
Page 21: Diagram
Diagram 10. Diagram Selection of required cross section for extension of cables and power lines This procedure takes into consideration. The ohmic and inductive resistance of the line with an admissible loss of voltage of 5% and cos phi = 0,8 as per voltage-frequency-curves. -
Page 22: Labels
Labels 11. Labels Warning: Do not operate without safety guards. Read and understand instruction book. SK00682GB.fm... - Page 23 Disposal 12. Disposal 12.1 Environmentally friendly reuse Provide for environmentally friendly reuse of the machine. Comply with all regional regulations and directives such as the European directive regarding old electric and electronic devices. Do not add the device to normal waste disposal. Instead, it should be collected separately.
- Page 24 Disposal T01088GB.fm...
- Page 25 Wacker Construction Equipment AG, Preußenstraße 41, 80809 München hereby certify that the construction equipment specified hereunder: 1. Category: Breakinghammer 2. Type: EH 27/115 3. Equipment item number: 0008396 4. Operating weight: 27 kg has been evaluated in conformity with Directive 2000/14/EC:...
- Page 27 DIN EN ISO 9001 Certificate Prüf- und Zertifizierungsinstitut VERBAND DER ELEKTROTECHNIK ELEKTRONIK INFORMATIONSTECHNIK e.V. C E R T I F I C A T E Registration-Number: 6236/QM/06.97 This is to certify that the company Wacker Construction Equipment AG Wacker-Werke GmbH & Co. KG at the following locations Head Office Munich Preußenstraße 41...
- Page 28 Wacker Construction Equipment AG Preußenstraße 41 80809 München Tel.: +49-(0)89-3 54 02-0 Fax: +49-(0)89-3 54 02-390 Wacker Corporation - P.O. Box 9007 - Menomonee Falls, WI 53052-9007 - Tel.: +1-(1)(262)-255-0500 - Fax: +1-(1)(262)-255-0550 - Tel.: (800)770-0957 Wacker Asia Pacific Operations-Skyline Tower, Suite 2303, 23/F, 39 Wang Kwong Road, Kowloon Bay, Hong Kong-Tel.: +852 2406 6032-Fax: +852 2406 6021...
