- Page 1 0203092en 11.2004 Vibratory plate DPU 5045H Operator´s Manual...
-
Page 3: H00556Gb
CONTENTS Type Item no. DPU 5045H 0007862 ... DPU 5045H - 750 wide 0007936 ... This machine has been equipped with an EPA certified engine. Additional information can be found in the engine manufacturers notes. WARNING Diesel engine exhaust and some of its... -
Page 5: Foreword
FOREWORD Foreword For your own safety and protection from bodily injuries, carefully read, understand and follow the safety instruc- tions in this manual. Please operate and maintain your Wacker machine in accordance with the instructions in this manual. Defective machine parts are to be replaced as soon as possible. All rights, especially the right for copying and distribution are reserved. -
Page 6: Table Of Contents
TABLE OF CONTENTS FOREWORD SAFETY INSTRUCTIONS General instructions Operation Safety checks Maintenance Transport Maintenance checks TECHNICAL DATA DESCRIPTION Field of application Dimensions Max. admissible inclination Description of function TRANSPORT TO WORK SITE, RECOMMENDATIONS ON COMPACTION Transport to work site Recommendations on compaction OPERATION Starting Forward and reverse motion... - Page 7 TABLE OF CONTENTS FAULTS Forward speed too low Reverse speed too low No reverse motion Loss of hydraulic oil Battery-charge warning lamp does not go off Engine does not start ELECTRIC WIRING DIAGRAM EC - CONFORMITY-CERTIFICATE...
-
Page 8: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS FOR THE USE OF VIBRATORY PLATES WITH COMBUSTION ENGINES General instructions Vibratory plates may only be operated by persons who * are at least 18 years of age * are physically and mentally fit for this job * have been instructed in guiding vibratory plates and proved their ability for the job to the employer * may be expected to carry out the job they are charged with carefully. -
Page 9: Safety Checks
SAFETY INSTRUCTIONS Make sure the soil or subsoil to be compacted has a high enough load carrying capacity. Use appropriate protective clothing while working or while carrying out maintenance work. When traveling backwards the operator has to guide the vibration plate laterally by its guide handle so that he will not be squeezed between the handle and a possible obstacle. -
Page 10: Technical Data
TECHNICAL DATA DPU 5045H DPU 5045H - 750 wide Item no. 0007862 ... 0007936 ... Forward/reverse speed m/min: 0 to 22 Surface compaction performance to 900 Operating weight without extension plates (440 mm) with extension plates (600 mm) with extension plates... - Page 11 TECHNICAL DATA (*) In accordance with the installed useful outlet power according to Directive 2000/14/EG. The sound pressure level at the operator‘s working place, determined according to the EN ISO 11204 standard, is equal to L = 90 dB(A) The weighted effective acceleration value, determined according to EN 1033 is 6 m/s The sound and vibration measurements were carried out and obtained with the machine working on crushed gravel at nominal engine speed.
-
Page 12: Description
DESCRIPTION Field of application The application range of these machines reaches from the trench and surface compaction, even with semi- cohesive soils, to the vibration of interlocking paving stones and sett pavements. Dimensions Max. admissible inclination T00464GB... -
Page 13: Description Of Function
DESCRIPTION Description of function The vibration required for compaction is produced by the exciter (13) which is firmly joined to the lower mass (5). This exciter (13) is designed as a central vibrator with aligned vibrations. Such a principle permits the di- rection of vibration to be changed by turning the eccentric weights (15). -
Page 14: Transport To Work Site, Recommendations On Compaction
TRANSPORT TO WORK SITE, RECOMMENDATIONS ON COMPACTION Transport to work site Conditions: To transport the vibration plate, only use suitable lifting equipment with a minimum load-bearing capacity of 500 kg. Always switch off engine before transporting the machine! Only attach suitable tackle at the central lifting point (18a) provided. The central lifting point is located ex- actly above the centre of gravity of the machine. -
Page 15: Operation
OPERATION Starting Conditions: Oil: Check oil level on oil dipstick (21), if necessary top up with Fuchs Titan Unic 10W40 MC using the filler nozzle (19). Fuel: When pouring diesel fuel into the fuel nozzle (20), maintain absolute cleanliness. Impurities in the fuel can cause breakdowns in the injection system and premature clogging of the fuel filter. -
Page 16: Switching Off
OPERATION Switching off ATTENTION! Never switch off the engine with the automatic decompression (2) as this inevitably results in damage to the valve drive and decompression mechanism. 1. Move the throttle control lever (8) to the stop. 2. When the engine is at a standstill, turn the ignition key (22) to the Stop position and pull out, control lamp goes off. -
Page 17: Mechanical Oil Pressure Control
OPERATION Mechanical oil pressure control It is necessary to reactivate the mechanical oil pressure control in the following cases: - after the initial filling - first filling - of the fuel tank or if the tank has run dry. - in the case of an automatic engine stop due to an inefficient engine oil supply. - after freeing the engine when in presence of extremely low temperatures. -
Page 18: Maintenance
MAINTENANCE Maintenance schedule Component Maintenance work Maintenance interval External hardware Check for tightness. approx. 8 hours after initial start-up Drive engine First oil change and filter. 25 hours after initial Valve clearance Cold engine: Check valve clearance, and adjust start-up if necessary. -
Page 19: Engine Oil
MAINTENANCE Engine oil Check oil level: Check oil level on oil dipstick (21). If the oil level is too low, top up with Fuchs Titan Unic 10W40 MC though the filler nozzle (19). Changing the oil: 1. Let engine warm up. 2. -
Page 20: Exciter
MAINTENANCE Exciter Check oil level: 1. Position vibration plate horizontally. 2. Open filler bore (30). 3. The oil level must reach the start of the thread of the filler bore (30). 4. If necessary, pour in Fuchs Titan Unic 10W40 MC through filler bore (30) (use funnel 0,75 l). 5. -
Page 21: Faults
FAULTS Forward speed too low Cause: - To little hydraulic oil in the centre pole head. - Air in hydraulic control. Remedy: - Top up hydraulic oil. - Bleed system. Reverse speed too low Cause: - Too much oil in centre pole head. Remedy: - Correct oil level in accordance with mark. -
Page 22: Electric Wiring Diagram
ELECTRIC WIRING DIAGRAM Bush plug Button switch Wire harnes Battery charge gauge Central plug Hexagonal head cap screw DIN933 - M8x16 Washer DIN125 - B8,4 Mass line Battery Positive pol strop Starter Nose cap Overcurrent switch E0127049GB-1... -
Page 23: Ec - Conformity-Certificate
Wacker Construction Equipment AG , Preußenstraße 41, 80809 München hereby certify that the construction equipment specified hereunder: 1. Category: Vibratory plate 2. Type: DPU 5045H 3. Equipment item number: 0007862 ... / 0007936 ... 4. absolute installed power: 6,1 kW... - Page 25 DIN EN ISO 9001 CERTIFICATE...
- Page 26 Wacker Construction Equipment AG Preußenstraße 41 80809 München Tel.: +49-(0)89-3 54 02-0 Fax: +49-(0)89-3 54 02-390 Wacker Corporation - P.O. Box 9007 - Menomonee Falls, WI 53052-9007 - Tel.: +1-(1)(262)-255-0500 - Fax: +1-(1)(262)-255-0550 - Tel.: (800)770-0957 Wacker Asia Pacific Operations-Skyline Tower, Suite 2303, 23/F, 39 Wang Kwong Road, Kowloon Bay, Hong Kong-Tel.: +852 2406 6032-Fax: +852 2406 6021...
