Summary of Contents for Wacker Neuson EH 9 BL/230
- Page 1 www.wackergroup.com 0203039en 06.2006 Electrik-hammer EH 9 BL/... Operator´s Manual...
-
Page 3: Foreword
Foreword Foreword For your own safety and protection from bodily injuries, carefully read, understand and follow the safety instructions in this manual. Please operate and maintain your Wacker machine in accordance with the instructions in this manual. Your Wacker machine will reward your attention by giving trouble-free operation and a high degree of availability. -
Page 4: Table Of Contents
Table of contents Foreword Safety instructions General Instructions ................3 Operation ....................3 Safety checks ..................5 Maintenance ..................6 Transport ....................6 Maintenance checks ................6 Technical data Description Application .....................9 Putting into operation ................9 During operation ..................9 Disassembly ..................10 Assembly .....................11 Maintenance Maintenance schedule ................12 Maintenance and lubrication ...............12 Malfunction Equipment failure ................13... -
Page 5: Safety Instructions
Drilling and breaking hammers Safety instructions Safety instructions for the use of drilling and breaking hammers with electric drive General Instructions 2.1.1 Drilling and breaking hammers may only be operated by persons who ∗ are at least 18 years of age, ∗... - Page 6 Safety instructions Drilling and breaking hammers 2.2.3 The operator has to switch off drilling and breaking hammers, to disconnect them from the electric mains and to store them in such a manner that they do not turn over be fore leaving the machines or going on breaks.
-
Page 7: Safety Checks
Drilling and breaking hammers Safety instructions 2.2.14 The tools always have to be in perfect conditions. 2.2.15 Do not operate this machine in areas where explosions may occur. 2.2.16 Do not misuse the electric cable to pull or lift up the unit or to pull the plug out of the socket. -
Page 8: Maintenance
Safety instructions Drilling and breaking hammers Maintenance 2.4.1 Only use original spare parts. Modifications to this machine are subject to the express approval of the Wacker Company. All liabilities shall be refused in case of nonobservance. 2.4.2 Disconnect the drilling and breaking hammer from the electric mains before carrying out maintenance and repair jobs. -
Page 9: Technical Data
Technical data Technical data EH 9 BL/ EH 9 BL/230 Loxam Item no 0008429 ... 0008917 ... 0008735 ... 0008753 ... Length x width x height 560 x 105 x 245 (without tool) Operating weight (mass) without tool Voltage 220 - 240 1~... - Page 10 Technical data EH 9 BL/115 EH 9 BL/115 WC Item no 0008436 ... 0008734 ... Length x width x height 560 x 105 x 245 (without tool) Operating weight (mass) without tool Voltage 110 - 127 1~ Power input Minimum generator output requirements for single connection Current consumption...
-
Page 11: Description
Description Description Application 4.1.1 Wacker’s breaking hammer is commonly used in building construction, civil engineering, facilities construction, municipal projects, concrete plants, artificial stone plants, foundries, installation projects, and many other applications. The breaking hammer is very well suited for handling natural and artificial stone and every type of masonry and concrete. -
Page 12: Disassembly
Description 4.3.2 Lock button Lock control lever by means of lock button when using the hammer for long breaking operations. When pression on control tongue, lock button is released. 4.3.3 Handle system at tool holder (consisting of two handle pieces) ∗... -
Page 13: Assembly
Description 4.4.2 Crankcase Access to rotor circlip: Remove screws, take bearing cover and crank mechanism out of crankcase. 4.4.3 Disassembly of handle Remove screws. Remove handle half and back handle. 4.4.4 Motor Access to stator pack and rotor: Remove screws, remove bearing bracket from crankcase. -
Page 14: Maintenance
Maintenance Maintenance Maintenance schedule Maintenance Component Maintenance work interval Check for perfect condition - if cable defective, Feed line replace. daily Miscellaneous Fan slits dirt - free - clean if necessary. Check shafts cutting edges Tools ifnecessary, sharpen, reforge or replace. Miscellaneous Regrease via grease nipples. -
Page 15: Malfunction
Malfunction Malfunction Equipment failure Cause Remedy for 115V machines: Make sure to have the correct voltage. Input voltage to high (>150V) or to low (<45V) Check extension cable for sufficient conductor cross section for 230V machines: Input voltage to high (>300V) or to low Let equipment cool off (<170V) Check supply cable incl. -
Page 16: Electric Wiring Diagram
Electric wiring diagram Electric wiring diagram Plug Conducting Switch white grey brown blue black Engine Frequency converter SK00686GB.fm... -
Page 17: Labels
Labels for the following machines: 0008429 ..., 0008732 ..., 0008735 ..., 0008736 ..., 0008737 ..., 0008738 ..., 0008753 ..., 0008917 ..., 0008918 ... Decal - Sound power level... -
Page 18: Disposal
Disposal Disposal Environmentally friendly reuse Provide for environmentally friendly reuse of the machine. Comply with all regional regulations and directives such as the European directive regarding old electric and electronic devices. Do not add the device to normal waste disposal. Instead, it should be collected separately. -
Page 19: Ec - Conformity Certificate
EC - Conformity Certificate Wacker Construction Equipment AG, Preußenstraße 41, 80809 München hereby certify that the construction equipment specified hereunder: 1. Category: Breaking / Drilling hammer 2. Type: EHB 9 BL/230 3. Equipment item number: 0008429 ..., 0008734 ..., 0008735 ..., 0008736 ..., 0008753 ..., 0008917 ... -
Page 21: Din En Iso 9001 Certificate
DIN EN ISO 9001 CERTIFICATE... - Page 22 Wacker Construction Equipment AG Preußenstraße 41 80809 München Tel.: +49-(0)89-3 54 02-0 Fax: +49-(0)89-3 54 02-390 Wacker Corporation - P.O. Box 9007 - Menomonee Falls, WI 53052-9007 - Tel.: +1-(1)(262)-255-0500 - Fax: +1-(1)(262)-255-0550 - Tel.: (800)770-0957 Wacker Asia Pacific Operations-Skyline Tower, Suite 2303, 23/F, 39 Wang Kwong Road, Kowloon Bay, Hong Kong-Tel.: +852 2406 6032-Fax: +852 2406 6021...
