Overview

The TP−780T and TP−780R are a 4K UHD, twisted pair receiver and transmitter for
HDMI, bidirectional RS−232 and IR signals. They support resolutions up to
4K@60Hz (4:2:0) UHD. The TP−780T converts HDMI, RS−232, and IR signals into
a twisted pair signal that it transmits to a TP−780R receiver. The TP−780R converts
the twisted pair signal back into HDMI, bidirectional RS−232 and IR signals. The
TP−780T and TP−780R support PoE (Power over HDBT). The TP-780T provides
power remotely over HDBT to the TP-780R where it might be difficult to connect an
external power supply. This allows a single HDBT LAN cable to provide both data
and electrical power to compatible devices.
The TP-780T and the TP-780R can form a transmission and reception system
either together or each device separately with another certified HDBaseT device.
The TP-780T/R transmitter and receiver feature:
•
A data transfer rate of up to 10.2Gbps (3.4Gbps per graphic channel)
•
Resolution support of up to 4K @60Hz (4.2.0) UHD
•
A range of up to 70m (230ft) at 2K, 40m (130ft) at 4K UHD resolutions.
•
HDBaseT™ technology
•
Power over HDBT that passes electrical power along with data on Ethernet
cabling. This allows a single cable to provide both data connection and
electrical power to compatible devices
•
HDTV compatibility and HDCP compliance
•
HDMI support for Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed
Audio Channels, Dolby TrueHD, DTS−HD, CEC.
4
For optimum range and performance using HDBaseT™, use
Kramer's BC−HDKat6a cable. Note that the transmission range
depends on the signal resolution, source and display used. The
distance using non−Kramer CAT 6 cable may not reach these
ranges.
