Summary of Contents for Kramer TP-580CT
- Page 1 USER MANUAL MODEL: TP-580CT 4K USB Transmitter P/N: 2900-301511 Rev 1 www.kramerAV.com...
-
Page 2: Table Of Contents
Kramer Electronics Ltd. Contents Introduction Getting Started Overview Typical Applications Defining TP-580CT 4K USB Transmitter Mounting TP-580CT Connecting TP-580CT Connecting to TP-580CT via RS-232 Wiring RJ-45 Connectors Setting the DIP-Switches Powering via USB-C Port Powering TP-580CT Charging a USB-C-Enabled Device Technical Specifications TP-580CT –... -
Page 3: Introduction
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we... -
Page 4: Overview
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/il/quality/environment. -
Page 5: Typical Applications
Typical Applications TP-580CT is ideal for the following typical applications: • BYOD presentations in enterprise meeting rooms and education classrooms. • Long-distance AV signal extension in conference rooms, boardrooms, classrooms, and lecturing facilities. TP-580CT – Introduction... -
Page 6: Defining Tp-580Ct 4K Usb Transmitter
Kramer Electronics Ltd. Defining TP-580CT 4K USB Transmitter This section defines TP-580CT. Figure 1: TP-580CT 4K USB Transmitter Front Panel Feature Function USB-C IN Connector Connect to a USB-C AV source (that supports DisplayPort Alternate Mode). Charges sources (that support USB Power Delivery 2.0) up to 60W. -
Page 7: Mounting Tp-580Ct
Kramer Electronics Ltd. Mounting TP-580CT This section provides instructions for mounting TP-580CT. Before installing, verify that the environment is within the recommended range: • Operation temperature – 0 to 40C (32 to 104F). • Storage temperature – -40 to +70C (-40 to +158F). -
Page 8: Connecting Tp-580Ct
Kramer Electronics Ltd. Connecting TP-580CT Always switch off the power to each device before connecting it to your TP-580CT. After connecting your TP-580CT, connect its power and then switch on the power to each device. Figure 2: Connecting to the TP-580CT... -
Page 9: Connecting To Tp-580Ct Via Rs-232
Kramer Electronics Ltd. Connecting to TP-580CT via RS-232 You can connect to TP-580CT via an RS-232 connection using, for example, a PC. TP-580CT features an RS-232 3-pin terminal block connector allowing the RS-232 to control TP-580CT. Connect the RS-232 terminal block on the rear panel of... -
Page 10: Powering Via Usb-C Port
20V DC power adapter, as specified in the following table. Device Active Power USB-C Source Max Total USB Max Charging Current Supply Source Charging Voltage Charging Power 5VDC 9VDC Connected 20VDC/6A 15VDC 20VDC TP-580CT – Powering via USB-C Port... -
Page 11: Technical Specifications
23.2cm x 13.4cm x 9.7cm (9.1" x 5.3" x 3.8") Net Weight 0.24 kg (0.5lbs) approx.. Shipping Weight 0.96 kg (2.1lbs) approx. Accessories Included Power adapter and cord Specifications are subject to change without notice at www.kramerav.com TP-580CT – Technical Specifications... - Page 12 This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state. This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller.
- Page 13 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our website where updates to this user manual may be found. We welcome your questions, comments, and feedback.
