  • Page 1 K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODELS: TP-121EDID, XGA /Audio Line Transmitter TP-123EDID, /Audio/Data Line Transmitter TP-125EDID, /Audio/Data Line Transmitter PT-110EDID, XGA Line Transmitter P/N: 2900-000585 Rev 6...
  • Page 3: Table Of Contents

    Wiring the TP LINE IN/LINE OUT RJ-45 Connectors Acquiring the EDID Figures Figure 1: TP-121EDID XGA/Audio Line Transmitter Figure 2: Connecting the TP-121EDID XGA/Audio Line Transmitter Figure 3: TP-123EDID XGA/Audio/Data Line Transmitter Figure 4: Connecting the TP-123EDID XGA/Audio/Data Line Transmitter Figure 5: RS-232 PINOUT Connection...
  • Page 4: Introduction

    Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Video Products. Thank you for purchasing your Kramer TOOLS: TP-121EDID XGA/Audio Line Transmitter, and/or TP-123EDID, XGA/Audio/Data Line Transmitter, and/or TP-125EDID, XGA/Audio/Data Line Transmitter, and/or Kramer Pico TOOLS™...
  • Page 5: Getting Started

    Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer products away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building.
  • Page 6: Safety Instructions

    Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
  • Page 7: Overview

    STP cable. There are different levels of STP cable available, and we advise you to use the best quality STP cable that you can afford. Our non-skew-free cable, Kramer BC-STP is intended for analog signals where skewing is not an issue.
  • Page 8: About The Power Connectâ„¢ Feature

    About the Power Connect™ Feature The Power Connect feature applies as long as the cable can carry power. This feature is available when using STP cable and the distance does not exceed 50m (164ft) on standard CAT 5 cable. For longer distances, heavy-gauge cable should be used (TP cable is still suitable for the video/audio transmission, but not for feeding power at these distances).
  • Page 9: Your Tp-121Edid

    XGA signal (up to WUXGA, 1080p) and an unbalanced stereo audio signal and transmits them over CAT 5 cable to a receiver (for example, the Kramer TP-122N). It converts the unbalanced stereo audio signal to a digital audio (S/PDIF) stream before transmitting, to preserve the quality of the audio signal.
  • Page 10: Connecting The Tp-121Edid Xga/Audio Line Transmitter

    +12V DC connector for powering the unit Connecting the TP-121EDID XGA/Audio Line Transmitter You can use the TP-121EDID together with the TP-122N to configure a twisted pair transmitter and receiver system, to transmit the video and audio signals via CAT 5 cable.
  • Page 11 You can use a Kramer C-GMA/GMA cable (VGA 15-pin HD (M) + audio jack to VGA 15-pin HD (M) + audio jack) to make both connections on one cable. Cables are not supplied. The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com.
  • Page 12: Figure 2: Connecting The Tp-121Edid Xga/Audio Line Transmitter

    Figure 2: Connecting the TP-121EDID XGA/Audio Line Transmitter TP-121/3/5EDID, PT-110EDID - Your TP-121EDID...
  • Page 13: Technical Specifications - Tp-121Edid

    12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H WEIGHT: 0.3kg (0.67lbs) approx. ACCESSORIES: Power supply OPTIONS: RK-3T 19” rack adapter All measurements are based on the transmitter/receiver pair. Specifications are subject to change without notice at http://www.kramerelectronics.com TP-121/3/5EDID, PT-110EDID - Your TP-121EDID...
  • Page 14: Your Tp-123Edid

    XGA signal (up to WUXGA, 1080p), unbalanced stereo audio signal, and unidirectional (RxD) RS-232 control commands and transmits them over CAT 5 cable to a receiver (for example, the Kramer TP-124 XGA/Audio/Data Line Receiver). It converts the unbalanced stereo audio signal to a digital audio (S/PDIF) stream before transmitting, to preserve the quality of the audio signal.
  • Page 15: Connecting The Tp-123Edid Xga/Audio/Data Line Transmitter

    Figure 3: TP-123EDID XGA/Audio/Data Line Transmitter Feature Function EDID CAPTURE Button Press to acquire the EDID information from the display STATUS LED Illuminates during normal operation; flashes when acquiring the EDID ON LED Illuminates when receiving power XGA IN 15-pin HD (F) connector Connect to the XGA source LINE OUT RJ-45 connector Connects to the LINE IN RJ-45 connector on the TP-124 XGA/Audio Line Receiver...
  • Page 16 You can use a Kramer C-GMA/GMA cable (VGA 15-pin HD (M) + audio jack to VGA 15-pin HD (M) + audio jack) to make both connections on one cable. Cables are not supplied. The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com.
  • Page 17: Connecting The Rs-232 Port

     If necessary, set the H SYNC and V SYNC switches, on the underside By default, both switches are set down (for negative V SYNC and H SYNC polarity). Figure 4: Connecting the TP-123EDID XGA/Audio/Data Line Transmitter Connecting the RS-232 Port To control an RS-232 controllable remote device from a PC or RS-232 controller, prepare an RS-232 cable with a 9-pin D-sub connector at one end, and a 2-pin terminal block connector at the other end, as shown in...
  • Page 18: Technical Specifications - Tp123Edid

    Figure 5: RS-232 PINOUT Connection Connect this PIN on To this PIN on the the Terminal Block 9-pin D-sub Connector: Connector PIN 2 PIN 3 PIN 5 Technical Specifications – TP123EDID INPUTS: Video: 1 VGA/UXGA on a 15-pin HD connector Audio: 1 audio ANALOG 3.5mm mini jack OUTPUT: 1 RJ-45 OUT connector...
  • Page 19: Your Tp-125Edid

    XGA signal (up to WUXGA, 1080p), unbalanced stereo audio signal, and bidirectional RS-232 control commands and transmits them over CAT 5 cable to a receiver (for example, the Kramer TP-126 UXGA/Audio/Data Line Receiver). It converts the unbalanced stereo audio signal to a digital audio (S/PDIF) stream before transmitting, to preserve the quality of the audio signal.
  • Page 20: Connecting The Tp-125Edid Xga/Audio/Data Line Transmitter

    Figure 6 defines the TP-125EDID: Figure 6: TP-125EDID XGA/Audio/Data Line Transmitter Feature Function EDID CAPTURE Button Press to acquire the EDID information from the display STATUS LED Illuminates during normal operation; flashes when acquiring the EDID ON LED Illuminates when receiving power XGA IN 15-pin HD (F) connector Connect to the XGA source LINE OUT RJ-45 connector Connects to the LINE IN RJ-45 connector on the...
  • Page 21 Audio source (for example, the audio out of the PC) to the AUDIO IN 3.5mm mini jack You can use a Kramer C-GMA/GMA cable (VGA 15-pin HD (M) + audio jack to VGA 15-pin HD (M) + audio jack) to make both connections on one cable.
  • Page 22: Connecting The Rs-232 Port

    Figure 7: Connecting the TP-125EDID XGA/Audio/Data Line Transmitter Connecting the RS-232 Port To control an RS-232 controllable remote device from a PC or RS-232 controller, prepare an RS-232 cable with a 9-pin D-sub connector at one end, and a 3-pin terminal block connector at the other end, as shown in Figure TP-121/3/5EDID, PT-110EDID - Your TP-125EDID...
  • Page 23: Technical Specifications - Tp-125Edid

    RS-232 Pinout PIN 5 Connected to GND Connect this PIN To this PIN on the PIN 3 Connected to RxD on the Terminal 9-pin D-sub PIN 2 Connected to TxD Block Connector: Connector PIN 2 PIN 3 PIN 5 To PC ( 9-pin D-sub Figure 8: RS-232 PINOUT Connection Technical Specifications –...
  • Page 24: Your Pt-110Edid

    The PT-110EDID is a high-performance XGA line transmitter that inputs an XGA (up to WUXGA, 1080p) signal and transmits it over CAT 5 cable to a receiver (for example, the Kramer TP-122N XGA/Audio Line Receiver). The PT-110EDID is pre-programmed with default EDID information ready for the source even before capturing the EDID from the display.
  • Page 25: Connecting The Pt-110Edid Xga/Line Transmitter

    Figure 9: PT-110EDID XGA Line Transmitter Feature Function XGA IN 15-pin HD (F) Connect to the UXGA source Connector 12V DC +12V DC connector for powering the unit EDID CAPTURE Button Press to acquire the EDID information from the display (see Section STATUS LED Illuminates during normal operation;...
  • Page 26: Figure 10: Connecting The Pt-110Edid Xga/Line Transmitter

    3. Connect the LINE OUT RJ-45 connector on the PT-110EDID to the LINE IN RJ-45 connector on the TP-120, via CAT 5 cabling. CAT 5 cable has a range of greater than 300ft (>100m). For details of how to wire a CAT 5 LINE IN/LINE OUT RJ-45 connector, see Section 4.
  • Page 27: Technical Specifications Pt-110Edid

    Technical Specifications PT-110EDID INPUT: 1 VGA/UXGA on a 15-pin HD connector OUTPUT: 1 RJ-45 LINE OUTPUT connector RESOLUTION: Up to WUXGA & 1080p S/N RATIO: 69dB (worst case) COUPLING: POWER CONSUMPTION: 12V DC, 320mA OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F) STORAGE TEMPERATURE: -40°...
  • Page 28: Wiring The Tp Line In/Line Out Rj-45 Connectors

    Wiring the TP LINE IN/LINE OUT RJ-45 Connectors This section defines the TP pinout, using a straight pin-to-pin cable with RJ-45 connectors. Note, that the cable Ground shielding must be connected / soldered to the connector shield. Figure 11: TP PINOUT EIA /TIA 568B Wire Color Orange / White...
  • Page 29: Acquiring The Edid

    Acquiring the EDID The transmitter can acquire the EDID information from the connected display or it can acquire the default EDID. To acquire the display EDID, do the following: 1. Using a short cable, connect the XGA INPUT 15-pin HD connector of the transmitter to the XGA input connector of the display.
  • Page 31 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
