Invacare® LiNX
• Latched configuration
A latched configuration allows you to operate a motion
without continuously providing a demand.
A latched configuration can be a single powered seating
function or a four quadrant configuration.
1. Give demand to front or rear to operate seating
function.
2. Release demand.
Motion is deactivated as soon as joystick is
deflected again or when motion reaches its
end-of-travel.
56
Fig. 5-26
In a four quadrant configuration it is possible to mix
the motion operations, like displayed in the example.

5.15.2 Through External Switches

Not all configurations and combinations of powered
seating functions through external switches are
available on all products.
With an external switch, seating functions can be controlled
while driving and without using seating cards.
When the seating function is activated without a seating
card, a small overlay is displayed on the touch display,
to inform the user, that the seating is being controlled
externally. The overlay remains on the touch display for the
duration of the seating operation.
Fig. 5-27
