  • Page 1 Yes, you can. ® Invacare® Dragon Vertic Power wheelchair User manual...
  • Page 3 How can you get in touch with Invacare®? If you have any questions or need support, please contact your authorised Invacare® Dealer, who has the necessary know-how and equipment plus the special knowledge concerning your Invacare® product, and can offer you all-round satisfactory service. Should you wish to contact Invacare® directly, you can reach us in Europe at the following addresses and phone numbers.
  • Page 4 +44 (0)1656 77 62 20 Pencoed uk@invacare.com Bridgend CF35 5AQ WWW: www.invacare.co.uk United Kingdom Invacare Mecc San s.r.l. +39 0445 38 00 59 Via dei Pini, 62 Fax: +39 0445 38 00 34 I - 36016 Thiene (VI) italia@invacare.com ITALIA WWW: www.invacare.it...
  • Page 5 +46 (0)8 761 81 08 Fagerstagatan 9 sweden@invacare.com S-163 91 Spånga finland@invacare.com Sverige WWW: www.invacare.se Tillverkare: MÖLNDAL Invacare® Deutschland GmbH  : +46 (0)31 86 36 00 Kleiststraße 49 Fax: +46 (0)31 86 36 06 D-32457 Porta Westfalica ginvacare@invacare.com Deutschland LANDSKRONA ...

  • Page 6: Table Of Contents

    Table of Contents Chapter Page Introduction ...................10 Important symbols in this manual ..................11 Important symbols found on the vehicle ................13 Type classification and permissible use ................16 Indications...........................17 Counter indications ......................18 Usability ..........................18 Warranty ..........................19 Life expectancy........................20 Safety notes ...................21 General safety notes......................21 Safety information with regard to care and maintenance ...........24 Safety information on electromagnetic interference ............24 Safety information on driving and freewheel mode ............26...
  • Page 7 6.2.2 Safety information when ascending obstacles ..............37 6.2.3 The correct way to overcome obstacles ................38 Driving up and down gradients ...................39 Parking and stationary ......................40 Use on public roads ......................40 Pushing the wheelchair in freewheel mode ........41 Disengaging Motors......................41 Remotes ..................42 Adjusting the wheelchair to the user's seating posture ....43 Torques..........................44 Adjusting the seat depth .....................44...
  • Page 8 9.7.5 Setting the height of the remote ..................71 9.7.6 Adjusting the width of the armrests .................72 Adapting the height of the chest belt ..................74 Adjusting the backrest ......................75 9.10 Adjusting the headrest ......................76 9.10.1 Adjusting the height .......................76 9.10.2 Setting the position ......................77 9.11 Adjustment of the stand-up angle..................78 9.12...
  • Page 9 Care and maintenance ..............98 Repair instructions..............101 12.1 Repairing a flat tyre......................101 12.1.1 Repairing a flat tyre at the back (tyre type 3.00-8") .............102 Transport..................105 13.1 Transferring the wheelchair to a vehicle.................105 13.2 Securing the wheelchair for transport without passengers..........106 Refurbishment ................107 Disposal ..................107 Technical specifications .............108 Inspections Performed..............111...

  • Page 10: Introduction

    The decision whether the model is suitable for the user may only be taken by medical specialists with appropriate expertise. Invacare® or their statutory representatives can accept no liability in cases in which the wheelchair has not been adapted to suit the users’ handicaps.

  • Page 11: Important Symbols In This Manual

    This manual contains copyrighted information. This manual may not be reproduced or reprinted either partly or completely without previous written consent from Invacare® or its statutory representatives. We reserve the right to make any necessary alterations on the grounds of technical improvements.
  • Page 12 RISK OF CRUSHING! This symbol warns of a risk of crushing caused by being careless with heavy components. • Always follow the instructions to avoid injury to the user or damage to the product. Wear eye protection This symbol refers to the requirement for wearing eye protection, for example when working with batteries.

  • Page 13: Important Symbols Found On The Vehicle

    Important symbols found on the vehicle DO NOT DRIVE OVER UNEVEN GROUND! Danger of tipping over! DO NOT LEAN OUT OF THE RAISED VERTICALIZER! Danger of tipping over! THE VERTICALIZER IS NOT DESIGNED TO TRANSPORT MORE THAN ONE SINGLE PERSON! Danger of injury! NEVER DRIVE ON ASCENDING OR DOWNWARD SLOPES WHEN THE VERTICALIZER IS RAISED! Danger of tipping over! NEVER REACH INTO THE MOVING APPARATUS OF THE RAISED VERTICALIZER!
  • Page 14 This product has been supplied from an environmentally aware manufacturer. This product may contain substances that could be harmful to the environment if disposed of in places (landfills) that are not appropriate according to legislation. • The 'crossed out wheelie bin' symbol is placed on this product to encourage you to recycle wherever possible.
  • Page 15 If the symbol appears on a bright yellow sticker, the anchoring point is suitable for fixation of the wheelchair in a vehicle for use as a vehicle seat. This wheelchair may not be used as a vehicle seat! • This wheelchair does not satisfy the requirements of ISO 7176-19:2001 and may not under any circumstances be used as a vehicle seat or to transport the user in a vehicle.

  • Page 16: Type Classification And Permissible Use

    Type classification and permissible use The Dragon erect chair is a class B electric wheelchair (for use indoors and outdoors) with an ability to overcome curbstones and obstacles restricted to 40 mm. It serves the mobility of handicapped people requiring slight to medium clinical support. This vehicle was designed for persons whose ability to walk is impaired, but who are still in terms of their eyesight and physically and mentally able to operate an electric vehicle.

  • Page 17: Indications

    Indications Before using the Invacare® Vertic for the first time, you should consult your doctor! Before using the verticalizer on a daily basis, we recommend medical/physiotherapeutic accompaniment in order to become accustomed to the modified posture. Below is a list of conditions that might make the use of this mobility product advisable. The list is not necessarily complete or exhaustive, but rather provides examples as a general guideline.

  • Page 18: Counter Indications

    The decision as to whether the model is suitable for you as user rests exclusively with the adequately skilled specialised medical staff. Counter indications The Invacare® Vertic must not be used when any of the following conditions are present: • Person with vitreous bones.

  • Page 19: Warranty

    • You should immediately stop using your power wheelchair if its usability is restricted due to: - brake failure • You should immediately contact an authorised Invacare® dealer if the usability of your power wheelchair is restricted due to: - the lighting system failing or being defective...

  • Page 20: Life Expectancy

    Life expectancy We estimate a life expectancy of five years for this product, provided it is used in strict accordance with the intended use as set out in this document and all maintenance and service requirements are met. The estimated life expectancy can be exceeded if the product is carefully used and properly maintained, and provided technical and scientific advances do not result in technical limitations.

  • Page 21: Safety Notes

    Safety notes READ WELL BEFORE OPERATION! General safety notes Danger of injury if mobility device is used in any other way than the purpose described in this manual! • Only ever use the mobility device in accordance with the instructions in this User's Manual (see chapter "Type classification and permissible use"...
  • Page 22 Danger of injury if the mobility device is switched off while driving, for example by pressing the On/Off Button or disconnecting a cable, due to it coming to an abrupt, sharp stop! • If you have to brake in an emergency, simply release the joystick which will bring you to a halt. (refer to the joystick operating manual for more information).
  • Page 23 Danger of fire or breaking down due to electric devices being connected! • Do not connect any electric devices to your mobility device that are not expressly certified by Invacare® for this purpose. Have all electrical installations done by your authorised Invacare® Dealer.

  • Page 24: Safety Information With Regard To Care And Maintenance

    Safety information with regard to care and maintenance Danger of accident and loss of guarantee if maintenance is insufficient! • For reasons of safety and in order to avoid accidents which result from unnoticed wear, it is important that this electric mobility product undergoes an inspection once every year under normal operating conditions (see inspection plan contained in service instructions).
  • Page 25 WARNING: Danger of malfunction due to electromagnetic interference! • Do not switch on or operate portable transceivers or communication devices (such as radio transceivers or cellular phones) when the vehicle is switched on. • Avoid getting near strong radio and television transmitters. •...

  • Page 26: Safety Information On Driving And Freewheel Mode

    Safety information on driving and freewheel mode Danger of injury if the wheelchair tips over! • Inclines and declines can only be travelled up to the maximum safe slope (see chapter "Technical specifications" from page 108). • Always return the backrest of your seat or the seat tilt to an upright position before ascending slopes.
  • Page 27 Danger of breaking down in adverse weather conditions, i.e. extreme cold, in an isolated area! • If you are a user with severely limited mobility, we advise that in the case of adverse weather conditions DO NOT attempt a journey without an accompanying attendant! Danger of injury if your foot slides off the footrest and gets caught underneath the wheelchair when it is in motion! •...

  • Page 28: Safety Information Regarding Changes And Modifications To The Mobility Device

    EEC / MPG (Medical Devices Act) and only applies to the complete product. The CE marking is invalidated if components or accessories are replaced or added that have not been approved for this product by Invacare. In this case, the company that adds or replaces the components or accessories is responsible for the conformity assessment/ CE marking or for registering the wheelchair as a special design and for the relevant documentation.
  • Page 29 • Only use seating systems that have been approved by Invacare® for this power wheelchair. Electrical and electronic components which have not been approved by Invacare® for use with this mobility aid can cause fire hazards and lead to electromagnetic damage! •...

  • Page 30: Safety Information For The Verticalizer

    Safety information for the verticalizer CAUTION: Danger of tipping! • When the verticalizer is raised drive operation only serves positioning and not normal driving. • Never drive over uneven ground, on an upward or downward slope or over obstacles when the verticalizer is raised.
  • Page 31 CAUTION! The breast belt lock can lose strength due to soiling or wear! • The belt lock velcro strap must not be soiled or clogged with fluff, fabric residue or similar foriegn bodies! It must be in a clean, undamaged condition! •...

  • Page 32: Key Features

    Key features 1) Release handle for headrest adjustment 2) Sliding handle 3) Chest belt 4) Set screw for adjusting the position of the remote 5) Side section fastening screw 6) Disengaging lever 7) Knee strap unlocking lever 8) Remote 9) Knee strap 10) Foot plate...

  • Page 33: The Position Of The Labels On The Product

    The position of the labels on the product 1) Note: Remove the table before transporting 2) Identification label sticker on the actuator of the verticalizer (also included in the pass card) 3) Identification of the lashing eyes at the front and back Warning that the wheelchair may not be used as a vehicle seat...

  • Page 34: Getting In And Out Of The Wheelchair

    Getting in and out of the wheelchair Important information on boarding and alighting from the side. In order to board and alight from the side the armrest must be swivelled upward. A clothing guard can be installed as an option in connection with the travelling armrest. This must also be removed in order to board.
  • Page 35 Getting into the wheelchair: • Position your wheelchair as close as possible to your seat. This might have to be done by an attendant. • Switch your wheelchair off. • Apply the manual wheel lock of your wheelchair (if existing). •...

  • Page 36: Driving

    Driving NOTE The maximum load capacity that is stated in the technical data only states that the system is designed for this mass in total. However, this does not mean that one can sit a person with this body weight in the wheelchair without restrictions. Attention must be paid to the body proportions, such as height, weight distribution, abdominal girth, leg and calf girth and seat depth.

  • Page 37: Taking Obstacles

    • The rear mirror (if installed) is adjusted so you can look behind at all times without having to bend forward or shift your seating position. Taking Obstacles 6.2.1 Maximum obstacle height You can find information about maximum obstacle heights in the chapter entitled "Technical specifications"...

  • Page 38: The Correct Way To Overcome Obstacles

    6.2.3 The correct way to overcome obstacles Ascending Right • Approach the obstacle or the kerb slowly, head-on and at a right angle. • Depending on the wheel drive type, stop in one of the following positions: - In the case of centrally driven wheelchairs: 5 - 10 cm before the obstacle. - For all other drives: approx.

  • Page 39: Driving Up And Down Gradients

    Driving up and down gradients For information concerning the maximum safe slope, please see chapter "Technical specifications" starting on page 108. WARNING: Danger of tipping over! • Only ever drive downhill at a maximum of 2/3 of the top speed. Avoid sudden changes of direction or abrupt braking when driving on slopes.

  • Page 40: Parking And Stationary

    If you wish to use your wheelchair on public roads and lighting is required by national legislation, then your wheelchair needs to be equipped with an appropriate lighting system. Please contact your Invacare ® dealer if you have any questions.

  • Page 41: Pushing The Wheelchair In Freewheel Mode

    Pushing the wheelchair in freewheel mode The motors of the wheelchair are equipped with automatic brakes, preventing that the wheelchair starts rolling out of control when the joystick box is switched off. When pushing the wheelchair manually whilst freewheeling, the magnetic brakes must be disengaged. Disengaging Motors Danger of the vehicle running away! •...

  • Page 42: Remotes

    Disengaging motors: • Switch off remote. • Withdraw the locking pin (1). Push the engaging lever (2) forwards. If necessary, move the wheelchair slightly forwards and backwards during disengaging. The motors are now disengaged. Re-engaging motors • Pull the engaging lever (2) to the rear. The motors are now re-engaged.

  • Page 43: Adjusting The Wheelchair To The User's Seating Posture

    Adjusting the wheelchair to the user's seating posture CAUTION: Damage to wheelchair and accident hazard! It is possible that collisions can occur between wheelchair components due to various combinations of adjustment options and their individual settings! • The wheelchair is fitted with an individual, multiply adjustable seating system including adjustable legrests, armrests, a headrest or other options.

  • Page 44: Torques

    To optimally adjust the wheelchair to the user's needs, it is advisable to have the seat depth adjusted individually by an authorised Invacare® dealer. There are perforated rails under the seat for adjusting the seat depth. This results in the following seat depths: 38, 40, 42, 44 and 46 cm.
  • Page 45 What should be observed when adjusting the seat depth? If the seat depth adjustment is too short, the forces on the body whilst standing up are too great. If the seat depth adjustment is too long, the user can “collapse“ whilst standing up. Pre-requisites: •...
  • Page 46 The picture on the right shows the position of the seat plate guide screws (1) and the fastening screws of the perforated rails (2).
  • Page 47 • Loosen the seat plate guide screw (1). • Loosen the fastening screws of the perforated rails (2) using an Allen key and an open- ended spanner and pull out. • Adjust the perforated rails to the desired seat depth. •...

  • Page 48: Legrest

    Legrest 9.3.1 Setting the lower leg length of the legrest The adjustment range of the calf length depends on the seat height! Depending on the model, the calf length has two possible adjustment ranges (measured including the seat cushion): • 36...45 cm •...
  • Page 49 • Loosen the screws (1) using the Allen key. • Set the foot plate to the desired height. • Re-tighten the screws.

  • Page 50: Changing The Height Of The Backrest

    Changing the height of the backrest By cutting off a segment of the backrest sling (underneath the backrest cushion), the height of the backrest can be permanently shortened once by 5 cm. Requirements: • Allen key 3 mm • Scissors •...
  • Page 51 • Remove backrest cushion. To change the height of the backrest, first the covers (A) on the ends of the backrest support tubes need to be loosened.
  • Page 52 • Loosen and remove the screws (1) that hold the covers, using the 3 mm Allen key. • Turn each cover so that the gap (1) is pointing towards the front, positioned directly over the end of the fixation rod of the backrest sling.
  • Page 53 • Pull the backrest sling up through the opening. • Using the scissors, cut the last segment of the backrest sling off, as shown in the illustration.
  • Page 54 • Push the backrest sling and, if necessary, the fixation rod back down into the backrest frame. • Re-position the screws (1) in the covers on the ends of the backrest frame tubes and tighten with the Allen key.

  • Page 55: Restraining Straps For The Legs

    Restraining straps for the legs 9.5.1 Opening and closing the restraining strap CAUTION: If the retaining clamp lock is not correctly and completely closed, and the locking lever is then pressed down using force, the locking mechanism can break! There is then a hazard that the user can fall out of the wheelchair.
  • Page 56 WRONG! RIGHT! • Flip lever (1) over. The restraining bar is released. • Open the restraining strap (2) to the front. • If necessary, loosen the locking lever on the other side and remove the entire strap. • The restraining strap is re-fitted in the reverse order and closed.

  • Page 57: Adjusting The Position Of The Release Lever

    9.5.2 Adjusting the position of the release lever WARNING: Danger of injury, in case one of the fixation bolts loosens or falls out, as a result of incorrect assembly! • The lower nut on the fixation bolt must always be tightened to 15 Nm after all assembly work! Requirements: •...

  • Page 58: Adjusting The Retaining Bar And Knee Cushions

    9.5.3 Adjusting the retaining bar and knee cushions 9.5.3.1 Setting the depth of the restraining strap Pre-requisites: • 5 mm Allen key What should be observed when adjusting the distance of the knee cushion to the shin? If the distance of the knee cushion to the shin is too small, great pressure is asserted on the legs when standing up.

  • Page 59: Adjusting The Height Of The Knee Cushions

    9.5.3.2 Adjusting the height of the knee cushions Pre-requisites: • Crosstip screwdriver WARNING: Danger of injury! • The knee pads should not press directly on the knees! The upper edge of the knee pads should be positioned just below the upper end of the shin bone! •...
  • Page 60 • Loosen the screws (1) using the crosstip screwdriver and remove. • Move the knee cushions to the desired position. • Re-insert the screws and tighten.

  • Page 61: Setting The Width Of The Knee Cushions

    9.5.3.3 Setting the width of the knee cushions Pre-requisites: • 4 mm Allen key • Use the screw wrench to loosen the Allen screws (1). • Set the desired knee cushion position. • Re-tighten the screws.

  • Page 62: Posture Belt For The Legs

    Posture belt for the legs 9.6.1 Setting the knee cushion depth What should be observed when adjusting the distance of the knee cushion to the shin? If the distance of the knee cushion to the shin is too small, great pressure is asserted on the legs when standing up.
  • Page 63 • Adjust the required length. • Check to see whether the knee cushion depth is correctly adjusted.

  • Page 64: Setting The Knee Cushion Height

    9.6.2 Setting the knee cushion height WARNING: Danger of injury! • The knee pads should not press directly on the knees! The upper edge of the knee pads should be positioned just below the upper end of the shin bone! Pre-requisites: •...

  • Page 65: Attaching The Knee Cushion

    9.6.3 Attaching the knee cushion • Hang the knee cushion hook in the holder.
  • Page 66 • The knee cushion can now be used.

  • Page 67: Adjusting The Armrests And The Control Panel

    Adjusting the armrests and the control panel 9.7.1 Adapting the height of the armrests Pre-requisites: • 5 mm Allen key • Loosen the eight Allen screws (1) (only the four on the right side are to be seen in the picture). •...

  • Page 68: Setting The Angle Of The Swing-Up Armrest

    9.7.2 Setting the angle of the swing-up armrest Pre-requisites: • 5 mm Allen key • 13 mm open-ended spanner WARNING: Damage to the wheelchair may result if the height of armrests is unevenly adjusted! • The armrests should only ever be adjusted parallel to each other, never higher on one side and lower on the other! •...

  • Page 69: Setting The Resistance Of The Swing-Up Armrest

    9.7.3 Setting the resistance of the swing-up armrest The swing-up armrest is prevented from lowering under its own weight by the pre-set resistance. Pre-requisites: • 5 mm Allen key • Adjust the Allen screw (1) until the desired resistance of the armrest has been achieved.

  • Page 70: Adapting The Control Panel To The Length Of The User's Arm

    9.7.4 Adapting the control panel to the length of the user’s arm • Loosen the wing screw (1). • Set the remote to the desired length by pushing forward or backward. • Re-tighten the screw.

  • Page 71: Setting The Height Of The Remote

    9.7.5 Setting the height of the remote • Loosen the wing screw (1). • Set the remote to the desired height. • Re-tighten the screw.

  • Page 72: Adjusting The Width Of The Armrests

    9.7.6 Adjusting the width of the armrests The distance between the side sections can be adjusted by 5.5 cm on both sides (11 cm in total). Requirements: • Allen key 8 mm Where to find the adjustment screws The picture shows the position of the screws (1) (underneath the seat frame, hidden in the picture), that allow an adjustment to the width of the side sections.
  • Page 73 Doing the adjustment • Loosen the screw (1). • Set the side section in the desired position. • Re-tighten the screw. • Check the firm fit of the side section. • Repeat the process for the second side section.

  • Page 74: Adapting The Height Of The Chest Belt

    Adapting the height of the chest belt Pre-requisites: • 5 mm Allen key WARNING: Danger of falling out of the wheelchair, if the chest belt comes undone! • Make sure that the Velcro strips on the chest belt cover each other completely. •...

  • Page 75: Adjusting The Backrest

    • Loosen the Allen screws (1). • Adjust the height of the belt. • Re-tighten the screws. Adjusting the backrest The backrest can be optionally adjusted using an electric actuator. Please consult the instruction manual for your remote for information about electrical adjustment.

  • Page 76: Adjusting The Headrest

    9.10 Adjusting the headrest 9.10.1 Adjusting the height • Loosen the hand wheel (1). • Move the headrest to the desired height. • Re-tighten the hand wheel.

  • Page 77: Setting The Position

    9.10.2 Setting the position • Loosen the release handle (1,2 or 3). • Move the headrest to the desired position. • Re-tighten the release handle.

  • Page 78: Adjustment Of The Stand-Up Angle

    9.11 Adjustment of the stand-up angle Pre-requisites: • Screwdriver, flat, width of edge approx. 6 mm WARNING: The Verticalizer could be destroyed if the position of the upper shut-off switches is changed! • Never modify the position of the upper shut-off switches! The control box (1) for the limit stop of the verticalizer is to be found under the seat.
  • Page 79 • Use the screwdriver to carefully release the rubber cover at the upper end of the control box and remove. There are three limit switches in the control box, two at the upper end and one at the lower end. The lower limit switch (1) is the one used to adjust the stand-up angle.
  • Page 80 • Use the screwdriver to loosen the fastening screw on the limit switch (1). • Slide the limit switch upward or downward. • Upward = actuator is shut down earlier when standing up, user is erected to a lesser degree. •...

  • Page 81: Postural Belts

    9.12 Postural belts A postural belt is an option which can either be fixed to the wheelchair ex-works or can be retrofitted by your specialist dealer. If your wheelchair is fitted with a postural belt, your specialist dealer will have informed you about fitting and usage. The postural belt is used to help the wheelchair user keep an optimum sitting position.

  • Page 82: Adjusting The Postural Belt Correctly

    If the belt is only fastened with a bolted connection, ensure that the connection has not loosened or undone. You can find more information about maintenance work on belts in the service manual, which is available from Invacare®.

  • Page 83: Adjusting The Table (Option)

    9.13 Adjusting the table (option) CAUTION: Injury hazard or material damage if a power wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair. 9.13.1 Swivelling the table upward CAUTION! Risk of injury! When the tray is raised it does not lock in place in this position! •...
  • Page 84 • Raise the armrest slightly. • Swivel the table top downward and lower in a downward direction together with the armrest.

  • Page 85: Adjusting The Depth Of The Table

    9.13.2 Adjusting the depth of the table Pre-requisites: • 5 mm Allen key • Use the Allen key to loosen the screws (1, on both sides). • Adjust the table to the desired depth. • Re-tighten the screws.

  • Page 86: Operating The Verticalizer

    9.14 Operating the verticalizer CAUTION: Danger of tipping! • When the verticalizer is raised drive operation only serves positioning and not normal driving. • Never drive over uneven ground, on an upward or downward slope or over obstacles when the verticalizer is raised. CAUTION! The user can fall out of the seat if the restraining systems are not used.

  • Page 87: Electrical System

    Electrical system 10.1 Electronics protection system The vehicle drive electronics is fitted with an overload protection. If the drive is severely overloaded over a long period (e.g. during steep climbs) and, above all, at simultaneous high external temperatures, the electronic system can overheat. In this case, the vehicle performance is gradually reduced until it comes to a standstill.

  • Page 88: The Main Fuse

    NOTE A defective main fuse may be replaced only after checking the entire electric system. An Invacare® specialised dealer must perform the replacement. You can find information on the fuse type in chapter "Technical specifications" starting on page 108. The entire electric system of the wheelchair is protected by the main fuse against overloading.

  • Page 89: Batteries

    10.2 Batteries Power is supplied by two 12 V batteries. The batteries are maintenance-free and only need regular charging. In the following, you find information on how to charge, handle, transport, store, maintain, and use batteries. 10.2.1 Charging the batteries 10.2.1.1 General information on charging New batteries should always be fully charged once before their first use.

  • Page 90: How To Charge The Batteries

    10 °C. • Use only charging devices in Class 2. This class of chargers may be left unattended during charging. All charging devices which are supplied by Invacare® comply with these requirements.

  • Page 91: How To Disconnect The Batteries After Charging

    Risk of explosion and destruction of batteries if the wrong battery charger is used! • Only ever use the battery charger supplied with your vehicle, or a charger that has been approved by Invacare®. Risk of electric shock and damage to the battery charger if it gets wet! •...

  • Page 92: Storage And Maintenance

    10.2.2 Storage and Maintenance Follow the instructions listed below to ensure safe use and longevity of the batteries: • Always store the batteries fully charged. • Do not leave the batteries in a low state of charge for an extended length of time. Charge a discharged battery as soon as possible.
  • Page 93 The last 3 LED (two red and one orange) mean a remaining capacity of about 15 %. • Driving with blinking red LED’s means an extreme stress for the battery and should be avoided under normal circumstances. • When only one red LED is blinking, the Battery Safe feature is enabled. From this time, speed and acceleration is reduced drastically.

  • Page 94: Transporting Batteries

    • Under normal operation, once a month the battery should be discharged until all green and orange LED are off. This should be done within one day. A 16 hour charge afterwards is necessary as reconditioning. 10.2.4 Transporting batteries The batteries supplied with your electric vehicle are not hazardous goods. This classification is based on the German GGVS Hazardous Goods Road Transport Ordinances, and the IATA/DGR Hazardous Goods Rail Transport / Air Transport Ordinances.
  • Page 95 • Only ever transport damaged batteries in an appropriate acid-resistant receptacle. • Wash all objects that have come into contact with acid with lots of water. Disposing of dead or damaged batteries correctly Dead or damaged batteries can be given back to your dealer or directly to Invacare®.

  • Page 96: Removing The Batteries

    10.2.5.3 Removing the batteries CAUTION: Risk of fire and burns if battery poles are bridged! • When replacing the batteries the battery poles MUST NOT come into contact with metal parts of the wheelchair causing bridging. • Be sure to replace the battery pole caps after the batteries have been replaced. Pre-requisites: •...
  • Page 97 • Pull the battery pole caps (1) upward and push back in order to reach the battery poles. • Use the open-ended spanner to loosen the battery pole clamps. • Remove the batteries to the rear.

  • Page 98: Care And Maintenance

    Care and maintenance NOTE: Have your vehicle checked once a year by an authorised Invacare® dealer in order to maintain it's driving safety and roadworthiness. Cleaning the vehicle When cleaning the vehicle, pay attention to the following points: • Only use a damp cloth and gentle detergent.
  • Page 99 Maintenance work Seat and backrest upholstery: - Check for perfect working order. Breast belt - Breast belt must be tight fitting. Check Velcro strip for correct function. Velcro strip may not open by itself. Side panels and arm support: - Are all fixing elements fitted? - Can the armrests / side panels be removed and refitted without excessive use of force? - Are the armrests secured in their position?
  • Page 100 - Carefully clean all parts. When necessary Let your authorised Invacare® specialist dealer check your vehicle once every year to ensure that driving safety and functionality are retained. You can find a complete checklist for the inspection and maintenance work to be carried out in the workshop manual, which...

  • Page 101: Repair Instructions

    "Technical specifications" on page 108, or consult the Service Manual, available from Invacare® (in this connection please see the addresses and phone numbers in section "How can you get in touch with Invacare®?" on page 3). In case you require assistance, please contact your Invacare® Dealer.

  • Page 102: Repairing A Flat Tyre At The Back (Tyre Type 3.00-8")

    12.1.1 Repairing a flat tyre at the back (tyre type 3.00-8") Injury hazard! If the wheel has been insufficiently secured during assembly, it can become loosened during driving! • When refitting the drive wheels, tighten the Torx screw that secures the wheel to the hub to a torque of 30 Nm! •...
  • Page 103 Removing the wheel • Jack the vehicle up and place a block of wood underneath it to prop it up. • Remove the countersunk screw (1) using the Torx bit. • Remove the wheel from the axle. EXPLOSION HAZARD! The wheel will explode if the air pressure is not released from the tyre before disassembling the wheel rim! •...
  • Page 104 NOTE In case the old inner tube is to be repaired and used again, and it happens to get wet during repair, then it is easier to re-fit it if you powder it lightly with talcum powder. NOTE Re-assembly is done in reverse order. Make sure that the wheel is put back on the same side it was on, and that it runs in the same direction it did before it was removed.

  • Page 105: Transport

    Transport CAUTION: Injury hazard or material damage if a power wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair. 13.1 Transferring the wheelchair to a vehicle WARNING: The wheelchair is in danger of tipping over if it is transferred to a vehicle while the driver is still seated in the wheelchair! •...

  • Page 106: Securing The Wheelchair For Transport Without Passengers

    CAUTION: Injury hazard! ® • If you are unable to fasten your electric wheelchair securely in a transport vehicle, Invacare recommends that you do not transport it! • Before transporting your wheelchair, make sure the motors are engaged and that the Joystick Box is switched off.

  • Page 107: Refurbishment

    • Cleaning and disinfection. Please see chapter "Care and maintenance" on page 98. • Inspection according to service plan. Please consult service instructions, available from Invacare®. • Adaptation to the user. Please see chapter "Adjusting the wheelchair to the user's seating posture"...

  • Page 108: Technical Specifications

    Technical specifications The technical information provided hereafter applies to a standard configuration or represents maximum achievable values. These can change if accessories are added. The precise changes to these values are detailed in the sections for the respective accessories. Electric system Motors •...
  • Page 109 Driving qualities Speed • 6 km/h Min. braking distance • 1000 mm Max. safe slope ****** Verticalizer completely lowered • 7,9° (13,9 %) according to manufacturer’s specifications with 100 kg payload, 4° seat angle, 20° backrest angle Verticalizer raised • 0° (0 %) according to manufacturer’s specifications with 100 kg payload, 4°...
  • Page 110 **** Measured without seat cushion ***** The actual kerb weight depends on the fittings your mobility aid has been supplied with. Every Invacare® mobility aid is weighed when leaving the works. Please refer to the nameplate for the kerb weight (including batteries) measured.

  • Page 111: Inspections Performed

    It is confirmed by stamp and signature that all jobs listed in the inspection schedule of the Service and Repair Instructions have been properly performed. The list of the inspection jobs to be performed can be found in the Service Manual which is available through Invacare®. Delivery Inspection...
