OPERATION

3.1.4

Operational Status Display

ΔDP

Mode

Next Mode

Process

Sensor

Shows total change in measured dew point over the time base of

the trend graph

Shows current operation mode:

Measure, Standby, DCC, Max Cool, Data Hold

Status of Process Alarm.

Alarm is active

Alarm is inactive

For further information on alarm configuration see sections 3.2

and 4.6.

Indicates whether the sensor has established a condensate

formation, or if the system is in a transient condition:

Heating, Cooling, Control.

Optidew User's Manual

97551 Issue 1, February 2018
