OPERATION
Outputs
Output selector
arrows
Output Type
Parameter
Alarm
Minimum
Maximum
22
Outputs screen
Figure 17
Selects the output to be adjusted
Chooses the mA output range
Available input: 0-20mA, 4-20mA
Assigns the chosen calculated or measured parameter to this
output channel
Available input: DP, Temperature, Pressure, %RH, wvp, g/m
g/kg, ppm , Wet Bulb
V
If the selected alarm is tripped, then this output will be forced to
Namur alarm level (20.6mA).
Available input: None, System, Process, Both
The minimum output range for the selected parameter
Available input: Dependant on parameter
The maximum output range for the selected parameter
Available input: Dependant on parameter
