OPERATION
Display
Resolution
Temperature Unit
Pressure Unit
Timebase
Stability
Display Hold
Language
Brightness
24
Display screen
Figure 19
Changes the number of decimal places for all displayed
parameters
Available input: 1 DP, 2 DP
Measurement unit for temperature values
Available input: °C, °F
Measurement unit for pressure values
Available input: kPa, psig, psia, barg, bara
X axis span for trend graph on main screen
Input format: hh:mm
Limits: 00:01 to 10:00
Determines a stable measurement following DCC, which is
conditional to release Data Hold. Entered value is ΔDP over 30s.
Available input: 0.2 to 20
When enabled, values on display are also held during Data Hold
Available input: Off, On
Sets User Interface language
Available input: English, Deutsch, Español, Français, Italiano,
Português, USA, Russian, Chinese, Japanese
Display backlight control
Available input: 0 to 100%
