OPERATION
3.1.2 Customizable Readouts
The three readouts on the Main Screen can be configured by the User to show any of
the following parameters:
• Dew Point
• Temperature
• Pressure
• % Relative Humidity
• g/m
3
• g/kg
• ppm
V
• Twb
• wvp (water vapour pressure)
• Dew Point (pressure corrected)
To change a parameter:
1. Touch the readout once to enable parameter selection
2. Touch the left or right arrows to select the parameter to be displayed
3. Touch the centre of the readout to confi rm selection
Full Screen Mode
Any of the readouts can be shown in full screen mode by touching and holding the
readout.
