CC3100 and CC3200 SimpleLink™ Wi-Fi
.....................................................................................................
This document provides the design guidelines of a 4-layer PCB board, for the CC31xx and CC32xx
SimpleLink™ Wi-Fi
devices. Optimize the board's performance by following these suggestions during the board's design. The
first section is a brief overview of the SimpleLink Wi-Fi family of devices. The second section focuses on
the PCB specification; the third section addresses components placement, and board layer information.
The last section, on layout guidelines, covers the board's main sections such as RF, power, clock, digital
I/O, and the ground. Each section can be read independently.
In addition to this document, TI recommends verifying the schematic board design with the associated
schematic checklist.
1

Trademarks

SimpleLink, Internet-on-a-chip, E2E are trademarks of Texas Instruments.
ARM, Cortex are registered trademarks of ARM Limited.
Wi-Fi is a registered trademark of Wi-Fi Alliance.
All other trademarks are the property of their respective owners.
4
CC3100 and CC3200 SimpleLink™ Wi-Fi
Layout Guidelines
Things Solution Layout Guidelines
family of devices. The CC31xx and CC32xx are easy to lay-out, QFN-packaged
®
®
and Internet of Things Solution
Copyright © 2014–2018, Texas Instruments Incorporated
SWRU370B – June 2014 – Revised August 2018
Embedded Processing Applications
ABSTRACT
SWRU370B – June 2014 – Revised August 2018
User's Guide
®
and Internet of
Submit Documentation Feedback
