CC3100 SimpleLink™ Wi-Fi
and IoT Solution
Getting Started Guide
User's Guide
Literature Number: SWRU375D
June 2014 – Revised May 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CC3100 SimpleLink and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Texas Instruments CC3100 SimpleLink

Summary of Contents for Texas Instruments CC3100 SimpleLink

  • Page 1 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide User's Guide Literature Number: SWRU375D June 2014 – Revised May 2018...

  • Page 2: Table Of Contents

    Getting Started with the MSP430F5529 ....................... Configure Boards ....................... Run the Software ........................... Summary ........................Acronyms Used .......................... Revision History Table of Contents SWRU375D – June 2014 – Revised May 2018 Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...
  • Page 3 Launch Tera Term ....................... Tera Term VT ..................Macro Definition of SSID_Name ......................Launch Tera Term ....................... Tera Term VT SWRU375D – June 2014 – Revised May 2018 List of Figures Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 4: Trademarks

    WLAN Station application. The guide explains how to install an Integrated Development Environment (IDE), and then compile, download, and debug Getting Started with WLAN Station. Trademarks SimpleLink is a trademark of Texas Instruments. Microsoft, Windows are registered trademarks of Microsoft. Wi-Fi is a registered trademark of Wi-Fi Alliance.

  • Page 5: Getting Started With Simplelink Studio

    1. The jumpers on the CC3100BOOST should be connected as shown in Figure Figure 1. CC3100BOOST SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 6: Cc31Xxemuboost

    2. The jumpers on the CC31XXEMUBOOST should be connected as shown in Figure Figure 2. CC31XXEMUBOOST ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 7: Connect The Cc3100Boost To The Cc31Xxemuboost

    5. The CC3100BOOST is now visible in the Device Manager as shown in Figure 4. The user may see two COM ports instead of four. SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 8: Run The Software

    4. Select Build>Build Solution from the menu. 5. When building is complete, select Debug>Start Debugging from the menu. ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 9: Mingw Installation Screen

    10. For Toolchain for indexer settings, choose “MinGW GCC” as shown in Figure SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 10: Import Existing Code

    18. Click the C/C++ General menu, and select Paths and Symbols. Under the Includes tab, in the ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 11: Paths And Symbols

    23. Select the Getting_started project from Project Explorer, and from the menu select Project>Build SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...
  • Page 12 Getting Started with SimpleLink Studio www.ti.com Project. 24. Press Ctrl+F11 to start the program. ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 13: Getting Started With The Msp430F5529

    1. The jumpers on the CC3100BOOST should be connected as shown in Figure Figure 9. CC3100BOOST SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 14: Jumpers On The Msp430F5529 Launchpad

    2. The jumpers on the MSP430F5529 Launchpad should be connected as shown in Figure Figure 10. Jumpers on the MSP430F5529 Launchpad ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 15: Run The Software

    3. Under Select Search Directory, enter the path: C:\TI\CC3100SDK_<x.x.x>\cc3100- sdk\platform\msp430f5529lp\example_project_ccs . 4. Check the project getting_started_with_wlan_station and press Finish. SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 16: Select Ccs Projects To Import

    WPA and WPA2 security, define it as SL_SEC_TYPE_WPA. For WEP security, define it as SL_SEC_TYPE_WEP. ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 17: Launch Tera Term

    10. If the CC3100 successfully completes all steps, the serial output appears as shown in Figure SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 18: Tera Term Vt

    8. After building is finished, select Project>Download and Debug from the menu to start debugging. ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...

  • Page 19: Launch Tera Term

    9. If the CC3100 successfully completes all steps, the serial output appears as shown in Figure Figure 18. Tera Term VT SWRU375D – June 2014 – Revised May 2018 ® CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...
  • Page 20 WLAN – Wireless LAN CCS – Code Composer Studio GCC – GNU Compiler Collection ® SWRU375D – June 2014 – Revised May 2018 CC3100 SimpleLink™ Wi-Fi and IoT Solution Getting Started Guide Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...
  • Page 21 Changes from C Revision (March 2016) to D Revision ....................Page ..........................• Updated Note....................• Added Eclipse Output Console image. SWRU375D – June 2014 – Revised May 2018 Revision History Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated...
  • Page 22 IMPORTANT NOTICE FOR TI DESIGN INFORMATION AND RESOURCES Texas Instruments Incorporated (‘TI”) technical, application or other design advice, services or information, including, but not limited to, reference designs and materials relating to evaluation modules, (collectively, “TI Resources”) are intended to assist designers who are developing applications that incorporate TI products;...
