Please read this user
Please read this user
manual carefully prior to
manual carefully prior to
installation, use and
installation, use and
maintenance for
maintenance for
your own safety and in
your own safety and in
order to avoid damages
order to avoid damages
on your video magnifier.
on your video magnifier.
User manual
mezzo vario
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Reinecker mezzo vario
Summary of Contents for Reinecker mezzo vario
- Page 1 User manual mezzo vario Please read this user Please read this user manual carefully prior to manual carefully prior to installation, use and installation, use and maintenance for maintenance for your own safety and in your own safety and in...
-
Page 4: Table Of Contents
Special advice for transport and storage ..............8 Disposal of the unit according to EU directive 2002/96/EEC ........8 Power supply .......................8 Safety instructions ......................9 II. Instructions for the reading system mezzo vario ..........10 Delivery content ......................10 Optionally available ....................10 Installation of the system ...................10 Connection of the unit ....................11... - Page 5 Start-up mezzo vario ....................16 Mains operation ......................16 Power ON ......................16 Power OFF ......................16 Automatic save regulation for the device set-up ............16 Replacement of lighting ..................16 Mobility pack/Use of battery ..................17 Operation of rechargeable battery ..............17 Replace the rechargeable battery ..............17 Use of battery .....................17...
-
Page 6: General Information
Product description mezzo vario is an opto-electronic reading system, which magnifies text and pictures. It may be used permanently for private and professional appliance. The text or pictures are being captured by the integrated camera and then displayed on the monitor. -
Page 7: Medical Device
Safety advice mezzo vario has to be installed in closed and dry rooms only. Do not plug mezzo vario into an electrical circuit that is also being used for any life sustaining or support sys- tems. -
Page 8: Cleaning Of The System
● Relative air humidity 30% to 80% Disposal of the unit according to EU directive 2002/96/EEC mezzo vario contains electronic components. In order to avoid damage to the envi- ronment, the country-specific rules have to be respected. Power supply Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. -
Page 9: Safety Instructions
2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply which is included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. -
Page 10: Ii. Instructions For The Reading System Mezzo Vario
II. Instructions for the reading system mezzo vario Delivery content ● Reading system mezzo vario ● Power adapter 12V DC / 5000mA ● Adapter cable (country-specific) ● User manual ● Information sheet for repair cases Optionally available ● Mobility pack (battery and carrying case) ●... -
Page 11: Connection Of The Unit
Connect the power supply to a mains wall socket and plug the adapter end of the cord into the DC12V power supply socket located on the base plate of the mezzo vario. Note: The delivered power cable is to be used exclusively in connection with the mezzo vario. -
Page 12: Alignment Of Monitor
Alignment of monitor Due to the monitor’s technology contrast and brightness change depending on the angle of view. The highly flexible three-dimensional monitor arm enables the user to adjust the monitors height and angle according to their best ergonomic position. rotatable by 90 degrees... -
Page 13: Description Of The Control Elements
● Turn ON the light again by pressing the black button briefly. Note: Whenever the mezzo vario will be turned ON, the maximum light will be activated. Indicator for rechargeable battery Only operates with built-in battery, see page 17... -
Page 14: Control Panel Monitor
The last magnification set will be memorised and displayed when turning mezzo vario ON again. The current magnification will be displayed briefly at the downside of the screen (this display can be deactivated in the user menu). -
Page 15: Autofocus On/Off
Note: The camera is equipped with an autofocus. When turning the central button to the maximum magnification, objects of a height of approx. 7cm shall be displayed sharply. Sharpness can be enhanced in the internal menu or when switching to artifi- cial colour mode. -
Page 16: Start-Up Mezzo Vario
When you reset the device all settings used before will be activated again. Replacement of lighting The electronic magnifier is equipped with a high power LED Illumination. If replace- ment of the lamp is required it should only be done by a specialist or by Reinecker Vision GmbH. Important note: Please only use the power supply included in the delivery. -
Page 17: Mobility Pack/Use Of Battery
The battery is only fully charged once the yellow charging light turns off. ● If mezzo vario will not be used for a long time, please charge the battery completely. Even if switched off, mezzo vario may discharge. Total discharge might damage the battery. -
Page 18: Battery Charging
● mezzo vario can be used again in battery mode ● mezzo vario can be used and operated whilst it is being charged Operating time once the battery had been fully charged ● With a 16" class monitor: approx. 2,5 hours, depending on illumination used ●... -
Page 19: Adjust Menu Settings
Adjust menu settings Turn the central zoom button in order to navigate through the menu. Press the central zoom button in order to open the menu selection. Turn the central zoom button in order to change menu settings. Press the central zoom button in order to confirm menu settings. Navigate to “exit menu”... - Page 20 Main Menu Ruler / Mask Settings Ruler / Mask OFF | deactivate line marker and shadowing Ruler | activate line marker Mask | activate shadowing Ruler Position 0 to 100 | adjust line marker position Mask Position 0 to 100 | adjust shadowing Ruler Mode Horizontal | anlign line marker horizontally Vertical | anlign line marker vertically...
- Page 21 Overview: Advanced Settings Color Combination Setup Anti Reflection Mode Auto (5) Monitor Brightness Language English Perform White Balance White Balance Mode Auto Sharpness Settings OSD Messages Special Settings Return Main Menu Advanced Settings Color Combination Setup Color Combination 1- 6 Mode Disabled | Full Color | Grayscale | False Color Foreground...
- Page 22 Main Menu Advanced Settings Anti Reflection Mode OFF | ON | Auto (0-9) | adjust default value Monitor Brightness adjustment range from 37 to 100 Language English | German | French | Norwegian Perform White Balance execute white balance White Balance Mode Auto | One-Push Main Menu Advanced Settings...
-
Page 23: Check List: In Case Problems Occur
Main Menu Advanced Settings Special Settings Store User Settings Confirm selection to the user setting to save Recall User Settings Confirm selection to the user setting restore Reset to Factory Settings Confirm to the factory setting restore Expert Settings Access - only by authorized service Monitor size 16"... -
Page 24: Technical Characteristics
Technical characteristics ● LED flat screen monitor: 19" class (48cm) or alternitavely 16" class (41cm), height adjustable, vertically inclinable, rotatable camera: ● magnification range from approx. 1x - 100x ● System resolution: 1366 x 768 pixels ● Battery lithium polymer battery, replaceable Operating time of ●... -
Page 25: Warranty Information
Warranty Information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH. -
Page 26: Notes
Notes... - Page 27 Type: mezzo vario Serial-Number: Manufacturer: Reinecker Vision GmbH Final examination: Power supply : 100 - 240VAC 50/60 Hz over plug- in power supply : 12V DC / 5000mA Type: WTI205000 Power consumption: max. 80 Watt...
- Page 28 Reinecker Vision GmbH In case service is necessary, please International Contact contact your authorized distributor. sales department, customer relations: Sandwiesenstraße 19 DE-64665 Alsbach-Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: +49 62 57-93 11-0 Fax: +49 62 57-25 61 Email: info@reineckervision.com www.reineckervision.com...
