Timeguard LEDPRORFKB Installation & Operating Instructions Manual page 8

Dedicated pir light controller c/w rf remote control for ledpro floodlights

Table of Contents

6.7 Connect the 3 way PIR plug, by pushing the

6.8 Secure the PIR to the floodlight using the

plug and socket inside the floodlight together

until they lock. DO NOT FORCE. THE PLUG AND

SOCKET WILL ONLY FIT TOGETHER ONE WAY

AROUND (See Jumper Plug diagram).

4 fixing screws.
