• The floodlight will illuminate for approximately
35 seconds. This indicates the unit is wired
correctly. The unit is in Test Mode when the light
turns OFF.
• If the detection area is too big for your
requirements, try angling the PIR light controller
head downwards. This will reduce the detection
area should a smaller coverage be required.
Setting Up for Automatic Operation
(Auto Mode)
• When walk tests are complete, the unit can be set
into Auto Mode.
10
• The TIME ADJUST setting controls how long the
unit remains illuminated following activation
and after all motion ceases.
• The minimum time (fully anti-clockwise) is approx.
3 seconds, whilst the maximum time (fully
clockwise) is approximately 18 minutes.
• Set the control to the desired setting between
these limits.
• The DUSK/DAWN LEVEL ADJUST control determines
the level of darkness required for the unit to start
operating. The DUSK adjustment knob is indicated
by the 'Moon' and 'Sun' symbols).
