2. Switch on Instrument

After switch on the instrument (press <I/0>)
the main menu appears on the display.
There will be displayed sub-menus with
following functions (not visible sub-menus
could be displayed by scrolling with arrow
keys):
Comb. measure.
(Mean value
(Atmospheric boiler
(Fan burner
(Diagnostic gas
(Pressure tests
(Data processing
Adjustments
Control
To perform measurements, select with the cursor keys the sub-menu
"Gas analysis" and confirm with <Enter>. The instruments starts
then a 1- minute calibration phase and the fuel types selection list is
displayed. The following fuel types acc. to 1
Fuel oil (B)
Natural gas (B)
City gas (B)
Coke oven gas (B)
Liquid gas (B)
Use the cursor keys to select the desired
fuel type and confirm with <Enter>. The
instrument will then enquire if you wish to
use the data bank (only with option „Data
processing").If you want to assign the
sampled data to a specific plant, so choose
„YES" with the cursor keys and confirm
with <Enter>. („NO" = measurement will
be performed without assignment).
ecom-B
: operate combustion measurement
: operate mean value measurement)*
: operate routine for atmospheric boilers)*
: operate routine for fan burners)*
: operate routine for gas fireplaces)*
: pressure tests according to TRGI)*
: assign measurements / Data transfer)*
: change adjustments of instrument
: check operating status of instrument (* = Option)
Comb.measure.
Mean value
Atmosph. boiler
Burn. w. blower
Diagnosis gas
Pressure tests
Data processing
Adjustment
Control
st
BImSchV are available:
Type of fuel
Fuel oil (B)
CO2max : 15.4
A1-fact. : 0.50
Select with
↑↓
Data processing
NO
Are you sure?
Continue with :
↵ ↵ ↵ ↵
↑↓
