6.9. The maintenance menu [MAIN]

6.9.1. Test sub-menu
The maintenance menu handles tests on the detector:
•
Flame simulation using the integrated test lamps
•
Detection tests using the LT15 test lamp or a test fire
•
Relay output and LED tests
Entering the test menu enables the temporary maintenance inhibition mode.
Without any manual intervention, the sensor come back to normal mode after 10 minutes.
6.9.1.1.
This menu initiates an optical test using the integrated test lamps.
Test results are indicated by the detector LEDs and on the TLU (message). However, there is
no action on the outputs (Relays and 4-20mA interface).
6.9.1.2.
This menu enables manually tests on detection, using either a test fire or a test lamp (Type
LT 15 SIMTRONICS).
In this mode, "false alarms rejection" algorithms are by-passed, to make a simulated alarm
easier to achieve.
All local indicators are activated (front cartridge LEDs, communication head red flashing
LED, remote controller display). While entering into the menu, the detector will ask for
outputs (current loop and relay) activation.
6.9.1.3.
This menu allows the user to force the detector output state for loop testing:
•
Individual test of the UV and IR LEDs.
•
Individual activation of each relay.
•
Setting analogue 4-20mA output. Available values are: 0 mA, 2 mA, 3.4 mA, 4 mA, 8
mA, 12 mA, 16 mA and 20 mA by pressing on ++ or -- pad.
6.9.2. Network
This menu is related to the Network variant of the detector (Syntel system).
MultiFlame DF-TV7
Flame simulation
LT15 test menu
Output test menu
