5.4. Using the LT15 test lamp

The LT15 is a flashing test lamp used for functional test of flame
detectors.
The emission spectrum of the lamp is between 280 nm (UV) and 5 µm
(IR).
The emission is pulsed to simulate the typical flickering of flames.
LT15 is certified Ex d IIC T6-T5 and suitable for operation in areas with
explosion hazard, (zone 1 and 2) in accordance with the EN 60079-0
and EN 60079-1 standards.
Using the TLU600 to enter in LT15 TEST mode, then activate the LT15 at a distance of 3-5m in
the axis of the flame detector to be tested.
The TLU menu commands are described in §6.6
For general information about the test lamp, refer to the LT15 Operating manual.
MultiFlame DF-TV7 Page 30 / 56 NOSP16358-03 [04/2016]
