3.2. Field of View (Cone of Vision)

α
: Maximum angle as defined in standard EN 54-10
max
(2006) - § 5.4
Angle at 50% sensitivity
(in accordance with FM 3260
standard)
The vertical viewing angle is limited by the self-test reflectors on a thin solid angle
DF-TV7-XVA0
DF-TV7-XTA0 AND DF-TV7-XTB0
Typical horizontal detection:
MultiFlame DF-TV7
Horizontal total
Vertical Up / Down
Page 15 / 56
DF-TV7-XTA0
DF-TV7-XVA0
DF-TV7-XTB0
30°
97°
20° / 35° 30° / 52°
Typical vertical detection:
NOSP16358-03 [04/2016]
and
35°
104°
