COMMISSIONING

5.1. Visual inspection

Make certain that all the operations of the "Installation" chapter have been achieved
correctly.
Pay particular attention on installation conformity, check the cables entry, the presence of O-
rings, and the connexion of the cartridge.
•
Check if the detection mode (UV/IR, 3IR) match with the marking

5.2. Power-up

The sensor is powered and operating when the green LED on the communication head is
flashing.
•
Check the connection to the control unit

5.3. Operational tests

All MultiFlame detectors are delivered set and tested. Some additional tests are necessary
to check the good working of the loop. Please make sure to have all authorizations needed
before running the following operations:
•
Check the states/information using the wireless configuration tool (TLU)
•
Check alarms delay setting : (factory settings)
•
5 seconds for XT versions
•
2 seconds for XV versions
•
Eventually, adjut the value up to 20 sec
The alarm state needs the fire detection to be continuously detected over the
full temporisation delay to be activated
SENSITIVITY SETTING
•
Factory settings :
•
100%
•
Except for XTB0 version (high sensitivity) 75%
•
Eventually adjust the sensitivity between 50% / 75% and 100ù of the maximum
coverage distance
•
Test the channel by trigging an alarm using the LT15 test lamp or force the output to
20mA via the TLU600.
