GENERAL INFORMATION

I N T R O D UC T ION
The CASCADE product continues the Codan Radio Communications tradition of module-based
products, where module capability expands into systems capability. CASCADE comes in a compact
rack form factor of 19-inch width and 4U height, providing the flexibility of a mix of transceivers /
power amplifier pairs; six receivers only or a mix of modules. From a transmitting point of view,
CASCADE offers up to two 125-watt power amplifier / transceiver pairs capable of not only P25
Phase I, but also LSM and P25 Phase II.
This guide covers operation information for the CASCADE System subrack and front panel, and
includes details on individual modules: DC-DC Power Supply, VHF Power Amplifier and VHF
Transceiver.
