System Setup
MO D U L E C ON F IGU R AT ION S
The following images identify the modules and their positioning in the subrack (see Figures 1–3).
Front Panel Removed –
Exploded View
Transceiver #1
Cascade System Modules Operation Guide
OG-CASC-SYS-MOD-1-0-0P
FIGURE 1: Complete CASCADE System
PA #1
Blanking Power
Panel Supply
FIGURE 2: CASCADE System – Front View Two Channels Option
PA #2
Transceiver #2
FIGURE 3: CASCADE System – Rear View Two Channels Option
PA #2
Transceiver #2
Power
Blanking
Supply
Panel
PA #1
Transceiver #1
