General Information
B A S E S TAT I ON / R EP EATER SP EC I FI C ATI O N S
RECEIVER (RX)
FCC Frequency Band:
IC Frequency Band:
Channel Spacing:
Channel Step Size:
Blocking Rejection:
Frequency Switching Range:
Reference Sensitivity (12 dB SINAD & 5% BER):
Adjacent Channel Rejection:
Conducted Spurious Output Power (Analog):
Intermodulation Rejection:
Hum & Noise Ratio:
L.O. Frequency Stability:
Audio Distortion (Analog):
Audio Output Level (600 Ω Balanced):
TRANSMITTER (TX)
FCC Frequency Band:
IC Frequency Band:
Channel Spacing:
Channel Step Size:
Frequency Switching Range:
RF Output Power:
Duty Cycle:
Undesired Emissions (Conducted Spurious):
Undesired Emissions
(Adjacent Channel Power Ratio):
Intermodulation Attenuation:
FM Hum & Noise Ratio:
Carrier Frequency Stability:
Audio Distortion (Analog):
VSWR Protection:
Emission Designators:
Cascade System Modules Operation Guide
OG-CASC-SYS-MOD-1-0-0P
150.8 to 173.4 MHz
148 to 174 MHz
12.5 kHz
1.25 kHz
≥ 100 dB
Full Band
≤ -120 dBm
≥ 60 dB
≤ -95 dBm (9 kHz to 1 GHz)
≥ 80 dB
*N/A
≤ ± 0.5 ppm
*N/A (≤ 2%)
*N/A
150.8 to 173.4 MHz
148 to 174 MHz
12.5 kHz
1.25 kHz
Full Band
10 to 125W; 1W steps, adjustable
100%
≤ -90 dBc
≥ 67 dB
≥ 70 dB
*N/A (≥ 45 dB Analog)
≤ ± 0.5 ppm
*N/A (≤ 2%)
Any (with fold-back)
8K10F1D, 8K10F1E, 8K10F1W, 8K10F7W,
8K70D1D, 8K70D1E, 8K70D1W,
8K70D7W,9K80D7D, 9K80D7E, 9K80D7W,
11K0F3E
