Appendix B: Parts Lists

B.1

General Information

The parts lists for the PCB assemblies contain:
1. Circuit Reference Number.
2. Descriptions, giving the value and type of component.
3. Manufacturer and Manufacturer's Part Number.
4. CODAN Part Number.
Table B.1 lists the abbreviations for resistor and capacitor types.
Resistors
CC- carbon composition
CF- carbon film
MF- metal film
MG- metal glaze
MO- metal oxide
WW- wire wound
Table B.1 Resistor and capacitor abbreviations.
Publication No: 15-02047
Note: Items having numeric references identifying specific
components or subassemblies may be encountered in the parts
lists included in this manual. These items, selected from master
manufacturing information, identify parts which either are useful
for maintenance purposes or relate to other items and may be
cross referenced in the remarks column.
Capacitors
AS- solid aluminium electrolytic
CC- ceramic multilayer chip
CE- ceramic
EL- wet aluminium electrolytic
M- stacked mica
PC- polycarbonate
PE- polyester
PP- polypropylene
PS- polystyrene
PT- PTFE
TA- solid tantalum
Appendices 8-3
