COMPLETE KIT CONTENTS
This kit contains parts for a range of different pump types - please ensure you correctly identify
the relevant parts for the pump being serviced before commencing. Also refer to the relevant
section for detailed instructions for the correct installation of the parts.
Fitting of incorrectly identified parts could lead to pump failure. If in doubt
contact PumpAssist on +44 (0) 800 31 969 80.
ITEM
1 Woodruff Key
2 Thrower
3 Seal Counterface
4 Rotary Seal
5 Washer
(ID 3/8 "x OD ¾ ")
6 Circlip
7 'O'-ring
(ID 66.40, c/sec 1.78)
8 Screws
(M6 x 35 mm)
9 Seal Applicator Tool
10 Clip
11 Magnetic Float
12 Screws
(M4 x 16)
Check to see that you have all the above items and that they are not damaged. If any damage is
found contact Stuart Turner Ltd within 24 hours of receipt.
•
PUMP PREPARATION
To prepare the pump to accept the service kit parts, each pump part must be removed noting
its exact position and sequence (Fig. 1).
Now clean all the individual parts. Before fitting the new service kit parts, the pump and seal
type must be identified.
•
CONTENTS
Section 1 Mechanical seal replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 2 Valve replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 3 Capacitor replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 4 Reed switch replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 5 Printed circuit board replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
QTY
1
1
1
1
1
1
1
4
1
(not shown)
1
1
4
- 2 -
ITEM
13 Reed Switch Tie Wrap
14 Flow Regulator
15 'O'-ring
(ID 24.6 mm)
16 Non-Return Valve Assembly
17 PCB
(not shown)
18 Strainer Relief Bush
19 Adhesive Foam Pad
20 Capacitor
(not shown)
21 Reed Switch
22 Screws
(K40 x 16 mm)
23 Inlet Assembly
24 Outlet Assembly
QTY
1
1
2
1
1
1
(not shown)
1
(not shown)
1
1
4
1
1
PAGE
3
5
8
10
13
