Stuart Turner FLOMATE MBF 12 Installation Instructions Manual page 15

Receptacles at 45
Fig. 27
•
INITIAL OPERATING INSTRUCTIONS
•
Consult instruction manual for commissioning instructions.
•
Do not run pump dry. Allow the water to be pumped to enter the pump body thus ensuring
the seal is lubricated before switching the pump on. Failure to do this will damage the
seal.
•
Carefully check pump and pipework for leaks whilst pump running and stationary before
leaving the installation unattended.
Stuart Turner Limited reserves the right to amend specifications without notice.
Blue wires
(approximately)
o
19
Fig. 26
Receptacles at 45
- 15 -
Red wire
(approximately)
o
Receptacles at 45 (approximately)
o
Black wire
