Grandstream Networks, Inc.
Analog IP Gateway GXW40XX
4, 8 or 24 FXS Ports
Models: 7898908277197 / 7898908277180
GXW40XX User Manual
www.grandstream.com
support@grandstream.com
Firmware Version 1.0.5.10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GXW40 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grandstream Networks GXW40 series

Summary of Contents for Grandstream Networks GXW40 series

  • Page 1 Grandstream Networks, Inc. Analog IP Gateway GXW40XX 4, 8 or 24 FXS Ports Models: 7898908277197 / 7898908277180 GXW40XX User Manual www.grandstream.com support@grandstream.com Firmware Version 1.0.5.10...

  • Page 2: Table Of Contents

    ..........................39 ONFIGURATION OWNLOAD ..................39 IRMWARE AND ONFIGURATION REFIX AND OSTFIX ................39 ANAGING IRMWARE AND ONFIGURATION OWNLOAD RESTORE FACTORY DEFAULT SETTING ....................40 Grandstream Networks, Inc. Page 2 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 3 3. S FXS P CREENSHOT OF ORTS ONFIGURATION OGIN 4. S CREENSHOT OF ROFILE ONFIGURATION 5. S CREENSHOT OF ROFILE ONFIGURATION 6. S CREENSHOT OF TATUS Grandstream Networks, Inc. Page 3 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 4: Welcome

    Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without the express written permission of Grandstream Networks, Inc. is not permitted. Grandstream Networks, Inc. Page 4 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 5: Connect Your Gxw40Xx Gateway

    1: D GXW4004-8 GXW4024 B IGURE IAGRAM OF ANEL GXW 400x PSTN Power Reset Console Line Supply Ports LAN/WAN Connection RJ-45 Ethernet Ports connection) Grandstream Networks, Inc. Page 5 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 6: Figure 2: 50 Pin Telco Connector

    TIP3 RING4 TIP4 RING5 TIP5 RING6 TIP6 RING7 TIP7 RING8 TIP8 RING9 TIP9 RING10 TIP10 RING11 TIP11 RING12 TIP12 RING13 TIP13 RING14 TIP14 RING15 TIP15 Grandstream Networks, Inc. Page 6 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 7: Table 2: Definitions Of The Gxw Display Panel

    Indicate status of the respective FXS Ports on the back panel LED 1–24 Busy - ON (Solid Green) Available - OFF Slow blinking FXS LEDs indicates Voice Mail for that port. Grandstream Networks, Inc. Page 7 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 8 LED POWER, READY and WAN lights are ON when device is up and run ning and successfully  registered to the SIP Server. Slow blinking of READY LED indicates that d evice has not registered with any SIP Service  provider. Grandstream Networks, Inc. Page 8 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 9: Gxw40Xx Features

    PSTN failover port on power PSTN Fail-over power failure failure G.711 + Annex I (PLC), G.711 + Annex I (PLC), G.711 + Annex I (P LC), Grandstream Networks, Inc. Page 9 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 10 BT, NTT, and DT MF-based BT, NTT, and DTMF-based Polarity Reversal / Wink EN55022/EN55024 EN55022/EN55024 EN55022/EN55024 FCC part15 Class B FCC part15 Class B FCC part15 Class B Grandstream Networks, Inc. Page 10 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 11: Hardware Specification

    32~104°F / 0~40°C Temperature - 90 (non- - 90% (no 10% - 90% (non-condensing) Humidity condensing) condensing) Safety FCC, CE FCC, CE FCC, CE, C-Tick Compliance Grandstream Networks, Inc. Page 11 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 12: Basic Operations

    SIP server. B y dialing *** and 7xx us er can reac h colleague connected to port “xx”. Voice Mail Number of voice mails “RESET” Enter “9” to reboot the device; or Grandstream Networks, Inc. Page 12 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 13: Placing A Phone Call

    2. Enter the target IP address using same format as above. Note: NO dial tone will be played between step 1 and 2. Destination ports can be specified by using “*” (encoding for “:”) followed by the port number. Grandstream Networks, Inc. Page 13 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 14: Call Hold

    Assume that Caller A and B are in conversation. Caller A wants to Attend Transfer B to C: 1. Caller A presses FLASH on the analog phone for dial tone. 2. Caller A then dials Caller C’s number followed by # (or wait for 4 seconds). Grandstream Networks, Inc. Page 14 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 15: 3-Way Conferencing

    1 is busy or times out. You can configure the ring timeout on the Profile page. Example configuration of a multiple Hunting Group: FXS Port #1: SIP UserID and Authenticate ID entered, Hunting group set to "Active" Grandstream Networks, Inc. Page 15 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 16: Inter - Port Calling

    Hunting Groups and is reg istered to SIP serve r only with one master number. In such cases users still wi ll be able to make inte r-port calls by using the IVR feature. Grandstream Networks, Inc. Page 16 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 17: Pstn Pass Through /Life Line

    Imbedded RADIUS client also supports request generated by Radius server to terminate calls when run out of pre-paid credit. Grandstream Networks, Inc. Page 17 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 18: Call Features

    If user hears call waiting beep, flash/hook will switch to the ne w incoming call. Also used to Flash/Hook switch to a new channel for a new call. Pressing pound sign will serve as Re-Dial key. Grandstream Networks, Inc. Page 18 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 19: Configuration Guide

    2. Open a we b browser, type in t he WAN side IP addre ss – for e xample: http://GXW40XX -IP- Address (the GXW40XX IP-Address is the WAN IP address for the GXW40XX). Grandstream Networks, Inc. Page 19 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 20: Important Settings

    DTMF via SIP INFO You can enable set priority of DTMF methods according to your preference, from Priority 1 to 3. This setting should be based on your server DTMF setting. Grandstream Networks, Inc. Page 20 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 21: Preferred Vocoder (Codec)

    IP addr ess, Subnet Ma sk, Default Router IP Static IP mode: address, DNS Server 1 (primary), DNS Server 2 (secondary) fields. These fields are set to zero by default. Grandstream Networks, Inc. Page 21 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 22: Rompt

    If set to “Yes”, the GXW40XX would act as an UPnP gate way for your UPnP enable Enable UPnP support applications. UPnP - Universal Plug n Play Note: This option is not present on GXW4024 Grandstream Networks, Inc. Page 22 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 23: Table 8: Status Page

    Program: This is the main software release. Boot and Loader are not changed often. Software Version Shows system uptime since the last reboot. System Up Time Grandstream Networks, Inc. Page 23 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 24: Table 9: Advanced Settings

    If the STUN server does not respond when the device bo ots up, the feature is disabled. Enables GXW40XX to download firmware or configuration file using either the TFTP Firmware Upgrade & or HTTP/S protocols. Provisioning Grandstream Networks, Inc. Page 24 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 25 “Check New Firmware only when F/W pre/suffix changes”, and “Always Skip the Firmware Check”. If set to Yes, configuration file is authenticated before being accepted. This protects Authenticate Conf File the configuration from unauthorized modifications. Grandstream Networks, Inc. Page 25 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 26 Disables the D irect IP Call function. Defaul t is “No”. If set to “Yes” direct IP- to-IP Disable Direct IP Call calling will not be supported. Grandstream Networks, Inc. Page 26 of 40 GXW40XX User Manual Firmware 1.0.5.10...
  • Page 27 Special secret string shoul d be preco nfigured according to RADIU S Server Primary Radius Server configuration Secret IP Address or FQDN of the secondary RADIUS Server Secondary RADIUS Server Grandstream Networks, Inc. Page 27 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 28: Table 10: Fxs Ports Settings

    SIP service subscriber’s account password for GXW40XX to register to (SIP) servers Password of ITSP. Any name to identify this specific user. Name Select the corresponding Profile ID (1/2) Profile ID Grandstream Networks, Inc. Page 28 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 29 Map to FXO Gateway IP This is used when peering with an FXO gateway of any brand. You have to specifically mention the IP and sip port where the call will be sent to. Sip port that will be annexed to the IP address above. and Port Grandstream Networks, Inc. Page 29 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 30: Table 11: Profile Settings

    SIP account. Ports 3 and 5 are not reg istered. Ports 3 and 5 will be able to p lace outbound calls using the SIP account of po rt 1, even if Outgoing Call without Registration is set to No Grandstream Networks, Inc. Page 30 of 40 GXW40XX User Manual Firmware 1.0.5.10...
  • Page 31 Default is No. If set to yes, use above DTMF order without negotiation Disable DTMF Negotiation Default is No. If set to yes, flash will be sent as a DTMF event. Send Hook Flash Event Grandstream Networks, Inc. Page 31 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 32 Wait Timeout Default is 4 seconds. Call will be completed within this time interval if no add itional key No Key Entry Timeout entry occurs. Grandstream Networks, Inc. Page 32 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...
  • Page 33 Note: In som e cases user wishes to dial strings such as *123 to activate voice mail or other application provided by service provider. In this case * shoul d be predefined inside dial plan feature and the Dial Plan will be: { [x*]+ }. Grandstream Networks, Inc. Page 33 of 40 GXW40XX User Manual Firmware 1.0.5.10...
  • Page 34 Default is No. If set to “Yes”, device will include only the first match vocoder in its 200OK Use First Matching response, otherwise it will include all match vocoders in same order received in INVITE. Vocoder in 200OK Grandstream Networks, Inc. Page 34 of 40 GXW40XX User Manual Firmware 1.0.5.10...
  • Page 35 SLIC Setting Select the value according to the local Telco standard where the GXW40XX is installed. Caller ID Scheme Please refer to the pull down list to select. Grandstream Networks, Inc. Page 35 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 36: Saving The Configuration Changes

    Grandstream also provide GAPSLITE s oftware package which contains our NAT friendly TFTP server a nd a configuration tool to facilitate the task of gene rating device configuration files. Grandstream Networks, Inc. Page 36 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 37: Grandstream Networks, Inc

    The GAPSLITE configuration tool is now free to e nd users. The tool and configuration template are available for download from http://www.grandstream.com/support/tools Grandstream Networks, Inc. Page 37 of 40 GXW40XX User Manual Firmware 1.0.5.10 Last Updated: 01/2012...

  • Page 38: Software Upgrade

    1. Unzip the file and put all of them under the root directory of the TFTP server. 2. Put the PC running the TFTP server and the GXW40XX device in the same LAN segment. Grandstream Networks, Inc. Page 38 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 39: Configuration File Download

    Day of the week(0-6): If automatic upgrade is enabled, service provider can further customize the behavior and distribute server load by setting hour of the day and/or day of the week for upgrade. Grandstream Networks, Inc. Page 39 of 40 GXW40XX User Manual Firmware 1.0.5.10...

  • Page 40: Restore Factory Default Setting

    2. Please be aware by default the GXW40XX WAN side HTTP access is disabled. After a factory reset, the device’s web configuration page can be accessed only from its LAN port. Grandstream Networks, Inc. Page 40 of 40 GXW40XX User Manual Firmware 1.0.5.10...
