Soft Focus Diffuser - ETC Source Four Quick Manual

ETC Quick Guide
Source Four LED Profile
used with R20 Relay Module or Unison Echo
with other equipment)
• Up to 32 device loads on the DMX daisy-chain
5: Connect the power cable to AC power.
WARNING:
Focus
1: Supply power and wait for the fixture to boot up.
2: Press [
3: Select Focus and press [
4: Adjust the fixture to the desired position.
5: Once the focus is set, press [

Soft Focus Diffuser

1: Install the diffuser into an A-Sized Pattern holder.
2: Install a pattern in front of the diffuser, if needed.
3: Insert the pattern holder with diffuser into the Pattern holder slot,
making sure the writing on the diffuser faces the front of the
fixture.
Address
A DMX address is not needed if using stand-alone or
master/slave control.
1: From the home screen, press [
2: In the Main Menu, scroll to DMX Start Address and press [
3: Use [
4: Press [
5: Press [
Source Four LED Profile
The fixture must be connected to a non-dimmable power source in order to avoid
damage to its internal power supply and other electrical components. Dimming
will damage the fixture and void the warranty.
] to open the Presets & Sequences menu.
] to turn on the LED array.
] to turn off the LED array and then [
] or [ ] to scroll to the desired fixture address.
] to select the address number.
] to return to the home screen.
®
Relay Panel (consult breaker-trip curves when used
] to open the Main Menu.
Page 3 of 8
] to return to the home screen.
].
ETC
