ETC Quick Guide
Source Four LED Profile
Quick
Setup
• For concerts and high impact lighting
High
• Enables quickest response, simple RGB
Impact
control and strobe channel for maximum
effect usage
• For video or film lighting
• Enables quick, comprehensive control of
white light via DMX or the fixture's
onboard user interface
• High-quality white-light output
The Studio Quick Setup is operational in all
Studio
fixtures for excellent white light
performance. It is the default setting for
Series 2 Daylight HD, Series 2 Tungsten HD
and Studio HD fixtures. In addition, Studio
Quick Setup enables stand-alone operation
from the User Interface on the back of the
fixture if no console is present.

Studio Quick Setup

From the home screen:
• To adjust the Intensity, press [
The range is 0 to 100%.
• To adjust the White Point, press [
The range is 2700 to 6500K.
• To adjust the Tint, press [
[ ] increases magenta and [
• To return to the Main Menu, press [
DMX Profiles
Lustr+ and Series 2: Lustr, Daylight HD, Tungsten HD, and Studio HD
DMX
Profile
Direct
RGB
Source Four LED Profile
Description
] & [
DMX
Channel Assignments
Channels
Channel
See
Assignments in Direct
10
Mode on
1 - Red
2 - Green
6
3 - Blue
(Ch. 4 not
4 - n/a
used)
5 - Strobe
6 - Fan Control
Profile
• Quick dimming response
• Boosted output for maximum intensity
RGB
• Reduced consistency of output
• White point: 5600K
• Linear dimming curve
• Regulated output for brightness
Studio
• Variable white point 2700K–6500K
• Variable + or – green (tint) with the
] or [ ].
] or [ ].
] or [ ].
] increases green.
].
Direct control of each individual color with a
separate master intensity channel. Color
calibration of LEDs is not active in this mode. The
page 7 . ten-channel profile will produce the highest
quality color crossfades.
Effectively addresses all seven colors via three
channels of control. RGB profile will produce
medium quality color crossfades.
Page 5 of 8
Features
consistency
Lustr+, Series 2 Lustr, and Studio HD
Notes
ETC
