ETC Source Four Quick Manual page 6

ETC Quick Guide
Source Four LED Profile
DMX
Profile
HSI
HSIC
Studio
Plus 7
Strobe
Source Four LED Profile
DMX
Channel Assignments
Channels
1 - Hue (coarse)
2 - Hue (fine)
3 - Saturation
6
4 - Intensity
5 - Strobe
6 - Fan Control
1 - Hue (coarse)
2 - Hue (fine)
3 - Saturation
7 4 - Intensity
5 - Strobe
6 - Fan Control
7 - Color Point (CCT)
1 - Intensity
2 - Color Point (CCT)
6
3 - Tint
(Ch. 4 not
4 - n/a
used)
5 - Strobe
6 - Fan Control
Plus7 Profile
7 additional See
Options
channels on
1 additional
channel
High resolution hue (two channels), saturation,
and intensity control.
HSI mode will produce color crossfades around
the color space.
High-resolution hue, saturation, and intensity
control as above, with the addition of a color
point channel to adjust the color temperature of
the fixture in both white light and color. Color
crossfade performance is the same as HSI.
Controls fixture as a white light unit. If no DMX
is present, (i.e. console input), a fixture can be
adjusted for these three parameters on the U/I at
the back of the unit.
Adds seven additional color control channels in
RGB, HSI, and HSIC input profile settings. For
example, HSI with 'Plus Seven' enabled becomes
a 15-channel profile.
The desired color and intensity are achieved by
using the HSI or RGB channels.
page 7
. Placing the Plus Seven channel at a value over
51% gives the fixture additional channels in its
profile.
Channels 9–15 represent the native colors of the
fixture and allow the operator to adjust
individual color channels to fine tune the color
output.
Variable strobe control: 0% is no strobe. The
fixture output will strobe more rapidly as the
strobe channel value approaches 100%.
Page 6 of 8
Notes
ETC
