ADV8005 Hardware Reference Manual
dac2_sel[2:0], Encoder Map, Address 0xE429[2:0]
This signal selects the data that is supplied to DAC 2.
Function
dac2_sel[2:0]
0
1 (default)
2
3
4
5
dac3_sel[2:0], Encoder Map, Address 0xE42A[6:4]
This signal selects the data that is supplied to DAC 3.
Function
dac3_sel[2:0]
0
1
2 (default)
3
4
5
dac4_sel[2:0], Encoder Map, Address 0xE42A[2:0]
This signal selects the data that is supplied to DAC 4.
Function
dac4_sel[2:0]
0
1
2
3 (default)
4
5
dac5_sel[2:0], Encoder Map, Address 0xE42B[6:4]
This signal selects the data that is supplied to DAC 5.
Function
dac5_sel[2:0]
0
1
2
3
4 (default)
5
dac6_sel[2:0], Encoder Map, Address 0xE42B[2:0]
This signal selects the data that is supplied to DAC 6.
Function
dac6_sel[2:0]
0
1
2
3
4
5 (default)

7.4. ADDITIONAL DESIGN FEATURES

This section outlines the various design features of the encoder which can be used to improve the overall video quality and the
performance in a system. Many of these functions are optional and should be set depending on a user's application.
Description
CVBS or Black Burst
Luma
Chroma
Y/G
Pb/B
Pr/R
Description
CVBS or Black Burst
Luma
Chroma
Y/G
Pb/B
Pr/R
Description
CVBS or Black Burst
Luma
Chroma
Y/G
Pb/B
Pr/R
Description
CVBS or Black Burst
Luma
Chroma
Y/G
Pb/B
Pr/R
Description
CVBS or Black Burst
Luma
Chroma
Y/G
Pb/B
Pr/R
Rev. A | Page 247 of 317
UG-707
ADV8005
