ADV8005 Hardware Reference Manual
UG-707
Config
Register
OSD_CORE
SPI
SPI
I2C
Master
Slave
Slave
FLASH
System
DDR2 Memory
MEM
Controller(CPU)
Figure 87: MCU as SPI Master Sending OSD Data Through
ADV8005
SPI Slave Interface
Additionally, the system MCU (SPI master) can program the external flash by looping SPI commands through the SPI slave (serial port 1) and
the SPI master (serial port 2) interfaces connected in a chain. In this mode, the OSD core just passes through MOSI, SS and SCLK signals from
the MCU to the flash. Note that the system MCU is responsible for any error protection in this mode, as shown in
Figure
88.
This option can be useful during the final debug stage of the OSD, in which the OSD design could be downloaded into the system SPI flash
memory through, for example, the USB or RSR232 port of the MCU.
This mode can be enabled using the
spi_loop_through
mode which controls the mux shown in
Figure
88.
Rev. A | Page 175 of 317
