UG-707
Location
Mnemonic
AA7
DDR_DQS[3]
AA8
NC/GND
AA9
DDR_A[8]
AA10
DVDD_DDR
AA11
DDR_A[2]
AA12
GND
AA13
DDR_CS
AA14
DVDD_DDR
AA15
DDR_CK
AA16
GND
AA17
DDR_DQ[11]
AA18
DVDD_DDR
AA19
DDR_DM[1]
AA20
DDR_DM[0]
AA21
GND
AA22
GND
AA23
DDR_DQ[3]
AB1
DDR_DQ[21]
AB2
DDR_DQ[19]
AB3
DDR_DQ[17]
AB4
DDR_DM[2]
AB5
DDR_DQ[30]
AB6
DDR_DM[3]
AB7
DDR_DQ[31]
AB8
DDR_DQ[29]
AB9
DDR_A[12]
AB10
DDR_A[6]
AB11
DDR_A[3]
AB12
DDR_A[0]
AB13
DDR_BA[0]
AB14
DDR_RAS
AB15
DDR_CKE
AB16
DDR_DQ[12]
AB17
DDR_DQS[1]
AB18
DDR_DQ[8]
AB19
DDR_DQ[13]
Type
Description if Unused
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
No
For New
ADV8005
connect/GND
pin. For Designs That Must Maintain
Consistency with ADV8005, this Pin can
be Grounded.
DDR interface
Float this pin.
Power
DDR Interface Supply (1.8 V).
DDR interface
Float this pin.
GND
Ground.
DDR interface
Float this pin.
Power
DDR Interface Supply (1.8 V).
DDR interface
Float this pin.
GND
Ground.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
Power
DDR Interface Supply (1.8 V).
DDR interface
Float this pin.
DDR interface
Float this pin.
GND
Ground.
GND
Ground.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Float this pin.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Float this pin.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Float this pin.
DDR interface
Float this pin.
DDR interface
Float this pin.
DDR interface
Float this pin.
DDR interface
Float this pin.
DDR interface
Float this pin.
DDR interface
Float this pin.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
DDR interface
Connect this pin to ground through a
4.7kΩ resistor.
Rev. A | Page 302 of 317
ADV8005 Hardware Reference Manual
Pin Type
Bi-directional digital IO
Designs, Float this
N/A
Digital output
N/A
Digital output
N/A
Digital output
Digital output
N/A
Bi-directional digital IO
N/A
Digital output
Digital output
N/A
N/A
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
Digital output
Bi-directional digital IO
Digital output
Bi-directional digital IO
Bi-directional digital IO
Digital output
Digital output
Digital output
Digital output
Digital output
Digital output
Digital output
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
Bi-directional digital IO
