ADV8005 Hardware Reference Manual
Packet Map
Address
0xF216
0xF217
0xF218
0xF219
0xF21A
0xF21B
0xF21C
0xF21D
0xF21E

6.6. SPARE PACKETS AND VSI SUPPORT

The user may configure the
registers. The ADV8005 features four such spare packets that can be enabled via the spare_pkt0_en, spare_pkt1_en, spare_pkt3_en, and
spare_pkt4_en controls bits. When a spare packet is enabled, the Tx transmits one of these enabled spare packets once every two video fields.
No control exists over the specific timing when these are sent; however, it is always before the leading edge of VSYNC. These spare packets allow
the ADV8005 to support the transmission of three Vendor Specific InfoFrames (VSI) as follows: VSI-Video, VSI-AUDIO and VSI-HDMI.
spare_pkt0_en, TX2 Main Map, Address 0xF440[0]
This bit is used to enable the Spare Packet 1.
Function
spare_pkt0_en
0 (default)
1
spare_pkt1_en, TX2 Main Map, Address 0xF440[1]
This bit is used to enable the Spare Packet 2.
Function
spare_pkt1_en
0 (default)
1
spare_pkt3_en, TX2 Test Map, Address 0xFBBF[2]
This bit is used to enable the Spare Packet 3.
Function
spare_pkt3_en
0 (default)
1
spare_pkt4_en, TX2 Test Map, Address 0xFBBF[1]
This bit is used to enable the Spare Packet 4.
Function
spare_pkt4_en
0 (default)
1
Packet Map Address
0xF2C0
0xF2C1
0xF202
0xF2C3
0xF2C4
Access Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
ADV8005 to send any type of packets or InfoFrames via the spare packets controls and associated configuration
Description
Disabled
Enabled
Description
Disabled
Enabled
Description
Disabled
Enabled
Description
Disabled
Enabled
Table 46: Spare Packet 1 Configuration Register
Access Type Register Name
R/W spare1_hb0[7:0]
R/W spare1_hb1[7:0]
R/W spare1_hb2[7:0]
R/W spare1_pb0[7:0]
R/W spare1_pb1[7:0]
Register Name Default Value
spd_pb19[7:0] 0b00000000
spd_pb20[7:0] 0b00000000
spd_pb21[7:0] 0b00000000
spd_pb22[7:0] 0b00000000
spd_pb23[7:0] 0b00000000
spd_pb24[7:0] 0b00000000
spd_pb25[7:0] 0b00000000
spd_pb26[7:0] 0b00000000
spd_pb27[7:0] 0b00000000
Default Value
0b00000000
0b00000000
0b00000000
0b00000000
0b00000000
Rev. A | Page 201 of 317
UG-707
Byte Name
Data Byte 19
Data Byte 20
Data Byte 21
Data Byte 22
Data Byte 23
Data Byte 24
Data Byte 25
Data Byte 26
Data Byte 27
Byte Name
Header Byte 0
Header Byte 1
Header Byte 2
Data Byte 0
Data Byte 1
