GP400 C
ONTROL
L
O C A T I O N
• The GP400 Control Module processor is located in the lower control box.
• The Matrix Module is located in the upper control box.
Diagnostic information can be found in Section 4: Troubleshooting.
Wiring information can be found in Section 5: Schematics.
M S
ODULE ETUP
"4069RT" Service and Parts Manual
G P4 0 0 C
Figure 2-19: Module Locations
Upper Controls
GP400
Matrix Module
ART_3156
M S
O N T R O L O D U L E E T U P
Lower Controls
GP400
Control Module
Terminal
Block
Module
Diagnostic LED
March 2014
Page 2-17
