Mec 4069RT Service And Parts Manual page 239

OPTION -- Outriggers
ITEM PART NO. QTY DESCRIPTION
1 21428 1
2 21429 1
3 50416 16
4 50001 16
5 21444 4
6 21436 4
7 50415 8
8 50446 16
9 50003 16
10 50050 16
11 REF --
12 92934 4
13 HDW8457 4
14 20998 4
15 50074 4
16 HDW5920 4
17 HDW9219 4
18 21477 4
19 HDW91395 4
• as req: as required
Front Outrigger Weldment
Rear Outrigger Weldment
Bolt, M8 x 25 Button Head
Washer, M8 Std.
Outrigger Cover Weldment
Outrigger Cover Plate
Bolt, M8 x 20 Button Head
Bolt, M12 x 120 Socket Head
Washer, M12 Std
Nut, M12 Nylock
Outrigger Cylinder -- See Section E
Proximity Sensor
Nut, 1/2 Nylock
Outrigger Pivot Bracket
Bolt, 1/2 x 3.5
Cotter pin, .120 x 1.00
Washer, 5/8 Std.
Outrigger Foot Pad
Clevis Pin, 5/8 x 5
• INCL: Included with assembly
