Functions Manifold, 2 - Mec 4069RT Service And Parts Manual

Functions Manifold, 2 of 2
ITEM PART NO. QTY DESCRIPTION
-- 93145 --
1 91151 3
2 91143 9
3 93502 2
4 91152 2
5 91477 2
6 92173 3
7 91464 1
8 93501 1
9 91147 2
10 93496 2
11 91008 2
12 91015 1
13 93497 1
14 91145 1
15 91009 1
16 91012 1
17 93494 2
18 93500 2
19 93493 1
20 93503 2
21 93499 1
22 93495 1
23 93498 1
• as req: as required
Functions Manifold Assembly, without fittings
Pilot-Operated Valve
Coil
Solenoid Valve, Rear Wheel Bypass
Pilot-Operated Valve
Check Valve
Coil
Solenoid Valve, Rear Wheel Bypass
Orifice Disc, .060
Solenoid Valve, High Torque/High Speed
Solenoid Valve, Drive
Solenoid Valve, Outrigger & Steering Directional
Hand Pump
Relief Valve
Solenoid Valve, Lift
Relief Valve
Manual Brake Release Valve
Flow Divider
Orifice Plug, .025
Check Valve
Counterbalance Valve
Shuttle Valve
Orifice Plug, .063
Flow Regulator
• INCL: Included with assembly
"4069RT" Parts Section
• NS: Not a Stock item • REF: Reference only
March 2014
Page E-7
