Name of the
screenshots
files

Creating a report

Configuring the
report
F
4 Press the
ILE
For trace results, the file is saved in the same directory than the file
used for screenshot.
For other page open and used for a screenshot, the file is saved in
the directory Print, into the disk.
The screenshot is saved in a file, which is automatically named as follow:
– Print_date (year/month/day)_time (hour/minut/second).jpg/png/pdf
Fig. 85 Example of screenshot, open in the Web Browser of
the 8000 V2 Platform
Once the results page of a function is opened (example: OTDR trace,
Power Meter results...), it can be exported in a report, using the 8000 V2
Platform.
To configure the report and choose the format of the report file:
1 On the Home page, press System Settings key to reach the
System Settings page.
2 In the Printer box, on the line Printer, select File (Formatted).
Choosing this option, you can save the open file in a JPG, PNG or
PDF file report, exactly as if the file was printed on paper.
Therefore, if the file is too large for one A4 page, several JPG, PNG
or PDF files will be created.
User Manual 78100000202 Rev. 003
key to find the JPG, PNG or PDF file in the Explorer
Chapter 10 File management

Creating a report
