Interference Hunting
InterferenceAdvisor and OneAdvisor 800
Page 1 of 10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Viavi InterferenceAdvisor
Summary of Contents for Viavi InterferenceAdvisor
-
Page 1: Table Of Contents
Interference Hunting InterferenceAdvisor and OneAdvisor 800 Table of Contents Scope ................................. 2 InterferenceAdvisor ........................... 2 Interference Hunting with InterferenceAdvisor ................3 InterferenceAdvisor Configuration ....................5 Interference Location with OneAdvisor 800 ..................... 8 Technical Support ............................ 10 Page 1 of 10... -
Page 2: Scope
1. Scope This document describes how to configure the InterferenceAdvisor and OneAdvisor 800 for interference hunting. The required products and parts to complete this procedure are as follows: Description Diagram OneAdvisor 800 with the following functions: OneAdvisor 800 platform equipped with the following... -
Page 3: Interference Hunting With Interferenceadvisor
(e.g. ≥ 2 MHz) o Channel Power: best for interference signals that have a broadband profile (e.g. ≥ 2 MHz) Interference Hunting with InterferenceAdvisor The following procedure describes the initial setup of InterferenceAdvisor and OneAdvisor 800 for interference hunting. Step Action... - Page 4 (USB-C), and into the OneAdvisor 800 (Ethernet port) via an Ethernet cable. Data connectivity options between InterferenceAdvisor and - Serial: use a USB-C to USB-A OneAdvisor 800 adapter, and connect it into the tablet (USB-C) and into...
-
Page 5: Interferenceadvisor Configuration
- Enter the IP address of the OneAdvisor 800 - Connect - Go with IA - OK InteferenceAdvisor Interface InterferenceAdvisor Configuration The following procedure describes the steps to perform Interference Hunting with InterferenceAdvisor. Step Action Description InterferenceAdvisor configuration: Frequency configuration: - Settings... - Page 6 Start interference hunting by selecting: - Spectrum Control - Play InterferenceAdvisor Measurement At the end of the measurement select: - Stop - Save InterferenceAdvisor Stop / Save Measurement - Enter the file name Page 6 of 10...
- Page 7 - Back to the main menu - History - Select the file saved - Change the scale InterferenceAdvisor Test Results and Post-Analysis InterferenceAdvisor Test Results Review and Post-Analysis Page 7 of 10...
-
Page 8: Interference Location With Oneadvisor 800
3. Interference Location with OneAdvisor 800 The InterferenceAdvisor solution specifies the location of the interference source. To identify the precise location of the interference, the OneAdvisor 800 conducts interference detection with directivity. This process utilizes its real-time persistent spectrum and employs a directional antenna for enhanced precision. - Page 9 Step Action Description Sound Indicator - Back - Setup - Sound Indicator - Alarm Reference (Marker) o Marker o Peak Search OneAdvisor 800 Real-time Spectrum Amplitude Configuration o Sound On - Alarm Reference (Line) o Line o Reference Level o Sound On OneAdvisor 800 Sound Indicator Configuration OneAdvisor 800 Real-Time Persistent Spectrum Page 9 of 10...
-
Page 10: Technical Support
4. Technical Support Technical support is provided by: Phone: 1-844-GO-VIAVI (1-844-468-4284) options 3-2-3 § Email: diagnostics.tac@viavisolutions.com § Regularly new firmware updates for the OneAdvisor 800 are released and it is recommended to keep the instrument in the latest firmware to provide all the enhancements and bug fixes.
