System design
4.1
Components
Refer to the packing slip and pictured components for specific parts and components
included with the system.
Note: The delivered system may look slightly different (without cover, only with different
camera bracket).
Four Position
Emission Filter
Selector
Access port
for optional
BioLite™
MultiSpectral
Light Source
Epi Overhead
White Light
UV-Safe Gel
Viewer
Window
81-0220-01 Rev R
®2
GelDoc-It
& ChemiDoc-It
®2
Imagers
Camera and Lens Kit
(actual configuration may
be different than shown in
System design
the photo)
Lighting and UV
Timer Switches
UV Safety
Interlock Switch
LED White Light
Plate (Optional)
Roll-Out
Transilluminator
