Available are: CCD™ 515 or 815 CCD scientific-grade monochrome CCD camera. All
cameras are Peltier cooled and offer full 16-bit file bit depth:
The 515 CCD camera has 2.1 MP resolution with Peltier cooling to - 57 °C from ambient.
The 515 CCD has a peak quantum efficiency of 50 % and is capable of binning from 1 x 1
to 8 x 8.
The 815 CCD camera has 8.1 MP (3296 x 2472) resolution with Peltier cooling to -57
°C from ambient. The 815 CCD has a peak quantum efficiency of 50 % and is also
capable of binning from 1 x 1 to 8 x 8.
All camera settings are factory pre-set for optimum performance when viewing gels, films or
membranes under low light level conditions. Contact Technical Support prior to making any
adjustments to the camera settings.
Lens Kit (Motorized or Manual)
The lens used comes in two configurations:

The motorized lens is controlled via VisionWorks Software.

The manual lens requires manual user adjustment.
Some lenses may be fitted with a close-up diopter. The diopter is used for focusing on
objects at the focal length of the darkroom.
